Low Noise Vacuum Homogenizer Cream Mixer , Powerful Soap Mixing Equipment

Vacuum Homogenizer Cream Mixer Introduction

Vacuum Homogenizer Cream Mixer is a set of mixing, dispersion, emulsification and homogenization, powder absorbing functions in one integrated system, a control system, but also with the peripheral oil, water tanks, the use of vacuum, heating / cooling system. Is a special equipment for producing medicinal ointment, cream, lotion and other high-grade.

Pharmaceutical Homogenizer Features and Performance

1. All tanks have 3 layers. The layers are made from high quality SS304L. Internal and external surface is treated by fine polishing which is safe and good looking.

2. Complex scraping board blending oar is suitable to every kind of complicated recipe and achieve optimizing effect;

3. Polytetrafluroethylene scraping board cater to body of blending groove and scrape out viscosity material on boiler wall;

4. Homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. It uses advanced German technology, with unique structure. The material moves of high-speed in the multi-gap between the rotor and the stator, which forms a strong hydraulic shearing. During few production, it can exert homogenizing effect fully.

5. Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high-capability cut, rubbing, centrifugal to make sure exquisite and slick cream; boiler body and pipe surface mirror polishing

6. Customer can choose frequency conversion timing homogenizer and highest rotate speed can reach 3500 r/min by ABB motor.

7. For the heating system and oil tank and water tank, the heating source is steam heating, which makes it fast to heat to guarantee a high working efficiency.

8. The asbestos insulation system is installed outside of the external layer. It not only helps thermal reduction, also protect the operators being burned.

9. The oil tank and water tanks are equipped with rating stirring dispersion device, so that oil and water could be heated more quickly and evenly.

10. Vacuum system is vacuum suction which applies Rotary Vane Vacuum Pump defoaming treatment (tap water can be recycled and cooling). It will increase homogenization effect makes sure no bubble in products.

Vacuum Homogenizer Cream Mixer Parameters

NOTE: Due to make toothpaste, the motor power have different type, so pls contact us, we will choose a suitable machine for you. we have engineer work for toothpaste factory more than 10 year also have machinery design experience.
