HMI Control Vacuum Homogenizer Cream Mixer / Cosmetic Lotion Making Machine

Vacuum Homogenizer Cream Mixer description

Vacuum Homogenizer Cream Mixer is mainly suitable for production of ointment and cream products in cosmetic and pharmaceutical plants. The emulsifying effect is more prominent for materials of high base viscosity and high solid content.

This series machine mixer uses the upper coaxial triple type blender, open lid by hydraulic lift lid.

Quick homogeneous agitator speed: 1150-3500 r/min (frequency control)
Slow scraper agitator speed: 10-40 r/min (frequency control)

Homogenizer using high shear vortex emulsifying mixer, stir slowly scraping the wall, close to the bottom and wall of the pot automatically.

By vacuum suction, especially for powder material, the use of vacuum suction could avoid dust. The whole process under vacuum conditions, to prevent the material stirring bubbles in high-speed, can achieve hygienic and aseptic requirements.
· Capacity:5L-2000L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS
Vacuum emulsifying equipment including:
· Vacuum emulsifying main machine
· Pre-mixing tank for sugar
· Vacuum system
· Hydraulic system
· Control system
· Platform made from SS304

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine
Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump
After finish one batch, customer can choose positive pressure or rotor pump for material out.

That is very important

Frequency speed control: Panasonic

Stirring scrap Material: SUS316L, Scrap material PTFE/Teflon

Motor: ABB

Touch screen: Siemens

ABB brand Motor

Frequency control Panasonic

Homogenizer motor: ABB

PLC Siemens touch screen control or button control
