24V Auto Compressor 11N690040 A50000674001 For Hyundai For

Construction Equipment WXTK114B



Parameter:

Compressor Pictures

Main Components of Automotive Air Conditioning Compressors:‌‌

1‌.‌Compressor‌: Acts as the heart of the AC system, compressing low-pressure, low-temperature refrigerant gas into high-pressure, high-temperature gas.

‌ 2.‌Condenser‌: Cools the high-temperature, high-pressure refrigerant gas into a medium-temperature, medium-pressure liquid, usually located near the radiator for heat exchange.

3‌.‌Evaporator‌: Evaporates low-temperature, low-pressure refrigerant liquid into gas, absorbing heat from the surrounding air to cool the vehicle's interior.

4‌.‌Expansion Valve/Throttling Valve‌: Controls the flow of refrigerant into the evaporator, allowing it to expand and absorb heat.

5‌.‌Drier/Receiver-drier‌: Stores refrigerant liquid and removes moisture and impurities.

6‌.‌Air Duct and Blower‌: Transports cooled air into the vehicle, enhancing passenger comfort.

7.‌Control Panel and Sensor‌: Adjust various AC functions and detect interior temperature and humidity for automatic system adjustments.‌

Working Principle of Automobile Air Conditioning Compressor

‌ The automotive air conditioning compressor is a crucial element in the vehicle's cooling system, operating on the principle of compressing refrigerant gas. It draws in low-pressure, low-temperature refrigerant from the evaporator, increasing its pressure and temperature through mechanical compression. This compressed refrigerant then flows to the condenser, where it releases heat to the outside environment, transitioning from a gaseous to a liquid state. The cooled liquid refrigerant returns to the evaporator, where it evaporates, absorbing heat from the cabin to provide cooling. The compressor's operation is regulated by sensors that monitor cabin temperature and refrigerant pressure, ensuring efficient and comfortable cooling.
