Adjustable Speed Vehicle Access Barriers Motorized Systems CE ISO Certification
Adjustable Speed Vehicle Access Barriers Motorized Systems CE ISO Certification
Adjustable Speed Vehicle Access Barriers Motorized Systems CE ISO Certification
Adjustable Speed Vehicle Access Barriers Motorized Systems CE ISO Certification
Specifications
Brand Name :
WONSUN
Model Number :
WSTP-115
Certification :
CE, ISO, SGS
Place of Origin :
China
MOQ :
1PC
Price :
negotiation
Payment Terms :
T/T,Western Union,Money Gram, Trade Assurance,Paypal etc.,
Supply Ability :
1000 Sets/Month
Delivery Time :
Delivery the guardrail in10days after receiving the deposit
Packaging Details :
Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Name :
Adjustable Speed Vehicle Barrier Gate Motorized Systems CE ISO Certificate
Product Brand :
WONSUN
Rating Power :
120W
Max boom length :
8 meters
Payment :
1) 30% T/T as deposit in advance and 70%T/T before loading
Description

Adjustable Speed Vehicle Barrier Gate Motorized Systems CE ISO Certificate

DZ-115 Vehicle Barrier Gate controller -- variable frequency type, is the enhanced Vehicle Barrier Gate control in which speed can be adjusted. Adopting full remote control mode, with the open /stop/close wire control interface, counting interface, special encoder limit interface, loop detector interface, infrared interface, open limit, close limit output interface, and communication interface. The remote control code is the learning code, and the receiver module adopts external superheterodyne reception.

Vehicle Barrier Gate Functions

1. Vehicle Barrier Gate steady function, sensitive reaction, low noise

2. The case shell is made of thickened steel which is shaped by 13 process flow. Without fading, waterproofing is not rusty and is durable.

3. High-sensitive limit switch, the pole can be instantly turned on and off accurate location.

4. The control system adopts hi-tech digital chip technology.

5. Vehicle Barrier Gate the anti-collision function. Protecting the passenger

6. Vehicle Barrier Gate the inductive function, of the digital vehicle detector

7. Vehicle Barrier Gate the movements adopt the most steady running mode –non-constant speed mode. Or the variable speed excogitation. (Slow – quick – slow ) .This function makes the operation steady and prolongs the working life.

Vehicle Barrier Gate Optional Accessories:

1. Loop detector: single loop detector or dual channel loop detector
2. Photocell
3. Flashlight
4. Boom rest/ arm holder
5. Control board
6. RS485 communication interface

Each Vehicle Barrier Gate will include:

1 pcs Vehicle Barrier Gate
1 pcs Vehicle Barrier Gate arm boom (from 1m to 6m can customized)
1 pcs Vehicle Barrier Gate control panel(built inside)
2 pcs Vehicle Barrier Gate remote controllers, 1 pc push button
1 pcs Vehicle Barrier Gate manual book


Vehicle Barrier Gate Specifications

Vehicle Barrier Gate Model

WSTP-115

Vehicle Barrier Gate Working Temperature

-40℃～+75℃

Vehicle Barrier Gate Voltage

220V±10%, 110V±10%, 50/60HZ

Vehicle Barrier Gate Rated power

80W

Vehicle Barrier Gate Relative humidity

≤90%

Vehicle Barrier Gate Remote control distance

≥30m

Vehicle Barrier Gate Net weight

48kgs

Vehicle Barrier Gate Speed

1S,1.8S,3S, 6S

Vehicle Barrier Gate Max boom length

6 meters

Vehicle Barrier Gate Motor Rotational speed

1400rmp

Vehicle Barrier Gate Protection Degree

IP44

Adjustable Speed Vehicle Access Barriers Motorized Systems CE ISO Certification
Communication with customers

1) Q: Connected power and pressed the open/close button but the Vehicle Barrier Gate no action.

A

Reason

Solution

1

Fuse blown

Check the fuse and power in the controller

2

The battery of the remote control powered off

Change a new one

3

External protection circuit break or at protecting status

Open the barrier door and click the OPEN/CLOSE button on the control box

4

Same frequency interference

Check photocell and loop detector


2) Q: Connected power and press the open/close button, the Vehicle Barrier Gate will move but even when it is in the right position, the motor still runs and does not stop.

A

Reason

Solution

1

Limit switch

Adjust the horizontal/vertical limit switch to the correct position

2

Main controller failure

Change a new one


3) Q: The motor running but the Vehicle Barrier Gate arm is not in action?

A

Reason

Solution

1

Vehicle Barrier Gate arm at 45° position where is hard to move

Unlock the clutch and manually rotate the arm to a horizontal or vertical position then try again

2

The tension of the balancing spring is not suitable

Adjust spring exactly

3

Low working voltage

Check the voltage and power


4) Q: When opening/closing, Vehicle Barrier Gate arm not reach the right position (90° vertical & 180° horizontal)?

A.

Reason

Solution

1

Length adjustment of connecting rod not correct

Open the Vehicle Barrier Gate door and unlock the clutch to check when the arm is at 90° vertical position if the master rod covers slave one; when the arm is at 180° horizontal position if the master rod and slave one are in the same straight line

2

Nuts on the limit switch loose

Tighten the nuts when arm at 90° vertical and 180° horizontal

Market Revenue(Previous Year) Total Revenue (%)
North America USD 63,608 1
South America USD 508,869 8
Eastern Europe USD 3,180,436 50
Southeast Asia USD 318,043 5
Oceania USD 127,217 2
Mid East USD 190,826 3
Western Europe USD 1,017,739 16
Domestic Market USD 954,130 15

1. Q: How long will your barrier work?

A: barrier life span more than 10 years.

2. Q: What should we do if there are problems during use?

A: We have 2 year guarantee. If any barrier problems you have, Welcome to email or call me! We will provide our best professional service for you.

3. Q: First-time import, how can I believe that you would send a product?

A: We are a verified company by Everychina, to make transactions successful.

4. Q: How to import your machines?

1. We will prepare the barrier and shipment for you after payment;

2. We will give you a bill of loading after the barrier departs our shipping port;

3. Our shipping agent will contact you when the barrier arrives;

4. You can pick up barriers by bill of loading.

Contact us for pricelist and catalog:
Sue Zhang
Email:sue@wonsunbarrier.com
Skype: SueZhang729
Whatsapp:+86 158 7925 9831
