DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
Specifications
Brand Name :
WONSUN
Model Number :
DZ-138
Certification :
CE/SGS
Place of Origin :
China
MOQ :
1PC
Price :
USD225
Payment Terms :
T/T,Western Union,Money Gram, Trade Assurance,Paypal etc.,
Supply Ability :
1000 Sets/Month
Delivery Time :
3-7 working days after received your payment
Packaging Details :
Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Product Name :
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
Color :
Orange,Golden,Gray-black,Customized
Material :
2.0mm cold roll steel sheet
Opeartion Time :
0.6S,0.9S,4S,adjustable
Arm Type :
stright arm,fence arm,folding arm
Rating Voltage :
AC90V~AC264V,DC24V,solar power,wind power
Gross Weight :
55KGS
Protection Grade :
IP54
Size :
352*312*959mm
Keywords :
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
Description
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
 Product Details

DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers

Technical Specifications
Name
DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers
Model DZ-138
Size 352*312*959mm
Rating Voltage AC90V~AC264V,DC24V,solar power,wind power
Color yellow,orange,blue,red,black,customized
Motor Power 100W
Speed Option 0.6S,0.9S,4S,adjustable
Material 2.0mm galvanized plate or cold roll plate with epoxy paint
Weight 55 KG
Operation Testing More than 10 million times
Arm Option

Straight arm, 1-6 m for option, 45*80mm or 45*100mm

Folding arm, 1-4.5 m for option, 90 degree or 180 degree

Fence arm, 1-5m for option, two fence or three fence
Working Temperature -45°C — +85°C
Remote Control Distance 100meters
Application Suitable for Highway, toll station, open-parking ground, underground parking, community,shopping center

Functions&Features

1. Manual release device to operate the barrier when power failure

2. Barrier motor with die-casting aluminum alloy is high-hermetic and easy for heat dissipation

3. Motor cooling fan to avoid the over-heating possibility

4. Automatic reversing when the barrier boom meets the obstruction

5. Auto closing realization through menu setting on the control panel

6. The barrier works well with infrared photocells, loop detectors, card readers, ticket dispensers, manual switch (wire control), and traffic light

7. RS485 Communication Module is compatible

8. Traffic light interface

9. Infrared Photocells (optional)

10. Support the external and internal Vehicle Loop Detector (optional)

Packing&Shiping

use strong carton case with air bubble filled inside to protect products and save your cost.

shipped in 3-7days after payment

Packing List

Items quantity items quantity
Paint-coated case 1 motor 1
Transmission 1 limit switch 1
Barrier arm 1 capacitor 1
Spring 1 circuit board 1
Remote control device 2 console control device 1
Installation kit 1

Company Information

DC 24V Servo Barrier Gate Encoder Controlled Car Parking Barriers

FAQ

Q: What's the order process?

A: Follow the steps on below to complete your order.

- 1. Inquiry

Provide us detailed information about your requirement, and we'll recommend the suitable products according to your request

-2. Quotation

Official quotation form with all clear specifications according to the order

-3. Invoice

Invoice will be issued once the quotation is confirmed.

-4. Payment

Payment shall be issued once the invoice issued. Full payment is acquired.

-5. Production

Bulk production shall be taking 15-25 working days.

-6. Delivery

by sea, air or courier. Detailed picture of package will be provided upon the service you've chosen. Packaging info will be sent upon confirmation.

Q: Do you provide samples ?

A: Yes, we could offer quoted price sample for you within 1-2 working days after payment confirmed.

Q: What is your terms of payment ?

T/T,Payapl, Western union

Our Service

1. One year free service is supplied(not including the arm)

2. Lifetime charged service is supplied

3. Technical service is supplied

4. OEM: we can customized machine case, color, logo for you, which accroding to your detailed requirements.

5. Technical support and aftersales service, it is a long term relatioship between us.

6. Price can be negotiable when you have big order quantity.
