Specifications
Brand Name :
WONSUN
Model Number :
DZG-2328
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 set
Price :
$599/set
Supply Ability :
3000 set/sets per month
Packaging Details :
Packed in bubble wrap firstly,and then reinforced with carton for outer packing
Product name :
AC Servo non-spring Super-high speed Barrier gate
Certificate :
CE ISO
OEM/ODM :
Support
Max Boom Length :
6 meters
Speed :
0.6sec~3sec, 0.2sec~3sec
Features :
Heavy duty, swing out, remote control
Description

Speed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier with 6m Arm

product description

Model No. AC Servo non-spring Super-high speed Barrier gate
Framework Material Cold-roll sheet
Beam Aluminum alloy
Dimension 340*340*950mm
Net Weight 48KG
Input Interface Photo cell, loop detector, parking system,wire control
Input 12V relay signal or Pulse Wide>100MS
Power Supply DC24V/AC110V/220V,50/60HZ
Motor Consumption 750W
Working Temperature -35°C to +65°C
Relative Humidity ≥90%
MCBF 5million time
Push Button Support
Remote Control Two button remote transmitter, Distance≤100m
Optional Accessories Loop detector; IR photo cell
Beam Length 6 meters
Opening/Close Time 0.6sec~3sec, 0.2sec~3sec

Functions and Features:

1 The running speed can be adjusted from 0.6sec~3sec, 0.2sec~3sec

2 Arm direction can be quickly interchanged

3 When power off,manual open and close arm,and lock itself

4 Wireless remote

5 Photocell IO pot output

6 Loop detector anti-collision IO output

7 Open and close control input

8 12V Traffic light output

9 Traffic light signal output

10 Open and close limit signal output

11 Counting (fleet)input RS485 communication input

12 24V Battery input port

13 Delay close arm function (1-300secadjustable)

14 Open and close arm speed deceleration function

15 One-key setting arm type with correspond speed

16 Arm auto reverse function (Forse adjustable)

17 Anti-collision alarm function (addictional sensiors and alarms are required)

18 RS485 Communication input

AC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and Airport

AC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and Airport

AC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and Airport​

AC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and AirportAC Servo Non-Spring Barrier Gate 0.2sec-3sec Speed Round Design for Expressway Bus Station and Airport

Our Services

Service for free:
1. One year free service is supplied(not including the arm and remote)

2. Lifetime charged service is supplied

3. Technical service is supplied

4. OEM: we can customized machine case, color, logo for you, which accroding to your detailed requirements.

5. Technical support and aftersales service, it is a long term relatioship between us.

6. Price can be negotiable when you have big order quantity.

Service for charging:

1. Broken by wrong installation

2. Broken by improper voltage

3. The surfaces of the barrier destroyed by wrong installation and usage

4. Overdue service items are out of our promise.

FAQ

Q: Are you trading company or manufacturer ?
A: We are a professional barrier gate manufacturer, indusrty and trade integration.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.

We can send it for you by DHL/Fedex/TNT/SEA/AIR or your requirments.
Q: How about payment terms our company provide?
A: T/T or Western Union or
Q: Do you provide samples ?
A:No,we don't provide free samples. The MOQ of our products is 1pc.
