Specifications
Brand Name :
WONSUN
Model Number :
DZ-2136
Certification :
CE ISO SGS
Place of Origin :
CHINA
MOQ :
1 set
Price :
$399/set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 set/sets per month
Packaging Details :
Packed in bubble wrap firstly,and then reinforced with carton for outer packing
Name :
Dual Motor Two-way barrier
Motor no-load speed :
1850r/min
Boom length :
6 meters
Working temperature :
-35°C to +65°C
OEM/ODM :
Supported
Place of original :
Guangdong,China
Description

5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot

Model No. DZ-2136
Framework Material Cold-roll sheet
Beam Aluminum alloy
Dimension 425*345*985mm
Net Weight 48KG
Input Interface Photo cell, loop detector, parking system,wire control
Input 12V relay signal or Pulse Wide>100MS
Power Supply DC24V/AC110V/220V,50/60HZ
Related Power 150W
Working Temperature -35°C to +65°C
Remote control system ≤100m(open,sunny weather)
MCBF 5million time
Push Button Support
Remote Control Two button remote transmitter, Distance≤100m
Protection class IP54
Beam Length 6M
Opening/Close Time 1.5sec~6sec

Functions and Features:

1 The running speed can be adjusted(1.5 sec-6sec)

2 Arm direction can be quickly interchanged

3 Barrier gate up and down signal relay switch output

4 R&G traffic light relay switch signal output

5 External loop detector signal anti-smashing interface

6 Infrared sensor signal anti-smashing interface

7 Count mode interface

8 Arm swing out function,when the vehicle hit the barrier gate,the arm can be swing out to avoid further damage on the vehicle and barrier machinery core

9 High-sensity arm auto reverse function (intensity can be adjusted )

10 Parking system interface

11 RS485 coomunication interface

12 Power off the backup battery inerface

13 Automatic arm lift function when power off (need to add power storage module)

14 5th DC Brushless Motor

15 1850 r/min Motor no-load speed

5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot

5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot

5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot

5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot​

5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot5th Generation Special Brushless Dual Motor Two-way barrier use in road traffic barrier parking lot

Our Services

Service for free:
1. One year free service is supplied(not including the arm and remote)

2. Lifetime charged service is supplied

3. Technical service is supplied

4. OEM: we can customized machine case, color, logo for you, which accroding to your detailed requirements.

5. Technical support and aftersales service, it is a long term relatioship between us.

6. Price can be negotiable when you have big order quantity.

Service for charging:

1. Broken by wrong installation

2. Broken by improper voltage

3. The surfaces of the barrier destroyed by wrong installation and usage

4. Overdue service items are out of our promise.

FAQ

Q: Are you trading company or manufacturer ?
A: We are a professional barrier gate manufacturer, indusrty and trade integration.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.

We can send it for you by DHL/Fedex/TNT/SEA/AIR or your requirments.
Q: How about payment terms our company provide?
A: T/T or Western Union or
Q: Do you provide samples ?
A:No,we don't provide free samples. The MOQ of our products is 1pc.
