Product Introduction
The Haval Second Generation Big Dog PHEV 2023 DHT-PHEV 105km Tide Electric Edition is a plug-in hybrid electric vehicle offered by Haval, a Chinese automaker. Here is a brief introduction to the vehicle in English:
The Haval Second Generation Big Dog PHEV 2023 DHT-PHEV 105km Tide Electric Edition is an advanced and eco-friendly SUV. It features a plug-in hybrid powertrain that combines a traditional internal combustion engine with an electric motor. This hybrid system allows for improved fuel efficiency and reduced emissions, making it an environmentally conscious choice.
With its electric range of 105 kilometers, the Big Dog PHEV offers the convenience of electric driving for shorter trips and urban commutes. The vehicle is equipped with a dual-clutch transmission (DHT), which provides smooth and efficient gear shifts.
The Big Dog PHEV boasts a spacious and comfortable interior, providing ample room for passengers and cargo. It features modern design elements, advanced technology, and a range of safety features to enhance the driving experience.
Company Profile
Chongqing Che Zhi Hui Tong Technology Co., Ltd
Establish time:2017
Address of headquarters:Chongqing, China
Developing theory:the company is dedicated to exporting renewable energy vehicles and adhering to the business philosophy of "quality first, customer foremost."
Oriented market:Initially focused on the domestic market, the company collaborated with major automotive manufacturers to provide sales and after-sales services. Since 2022, the company has expanded its business to Central Asia, Southeast Asia, Africa, South America, the Middle East, and other regions, exporting economy cars. In the same year, the company partnered with a new energy vehicle manufacturer to enter the international market for new energy vehicles, possessing the capability to inspect and repair the three-electric systems (battery, motor, and electronic control) of new energy vehicles. To enhance overseas services, the company has established branch offices in multiple locations.
CONFIGURATION
Haval second generation big dog PHEV 2023 DHT-PHEV 105km tidal electric version
Specification | Details |
---|---|
Manufacturer | Great Wall Motors |
Official Price | 165,800 CNY |
Segment | Mid-size SUV |
Fuel Type | Plug-in Hybrid |
Launch Date | September 2023 |
Engine | 1.5T 154hp L4 Plug-in Hybrid |
Electric Range (Ministry of Industry and Information Technology) | 80 km |
Electric Range (NEDC) | 105 km |
Electric Range (WLTC) | 80 km |
Total Electric Range (NEDC) | 1000 km |
Charging Time (Fast) | 0.37 hours |
Fast Charge Level | 30-80% |
Maximum Power | 240 kW |
Maximum Torque | 530 Nm |
Transmission | 2-speed DHT |
Dimensions (LxWxH) | 4705x1908x1780 mm |
Body Type | 5-door, 5-seater SUV |
Top Speed | 190 km/h |
0-100 km/h Acceleration | - |
WLTC Combined Fuel Consumption | 1.85 L/100km |
kWh/100km | 18 kWh/100km |
Electric Energy Consumption Equivalent Fuel Consumption | 2.04 L/100km |
Minimum Fuel Consumption at Low Charge State (Ministry of Industry and Information Technology) | 5.92 L/100km |
Minimum Fuel Consumption at Low Charge State (WLTC) | 5.92 L/100km |
Warranty Period | 6 years or 150,000 km |
Curb Weight | 2005 kg |
Gross Weight | 2400 kg |
Fuel Tank Capacity | 55.0 L |
Cargo Volume | 483-1362 L |
Engine Type | GW4B15D |
Displacement | 1499 mL |
Intake System | Turbocharged |
Engine Layout | Transverse |
Cylinder Arrangement | Inline |
Number of Cylinders | 4 |
Valves per Cylinder | 4 |
Compression Ratio | - |
Valve Mechanism | DOHC |
Maximum Power (Ps) | 154 Ps |
Maximum Power (kW) | 113 kW |
Maximum Power RPM | 5500-6000 rpm |
Maximum Torque | 233 Nm |
Maximum Torque RPM | 1500-4000 rpm |
Fuel System | Plug-in Hybrid |
Fuel Rating | 92# |
Fuel Supply | Direct Injection |
Cylinder Head Material | Aluminum |
Cylinder Block Material | Aluminum |
Emission Standard | National VI b |
Electric Motor Description | Plug-in Hybrid, 177 hp |
Motor Type | Permanent Magnet/Synchronous |
Total Motor Power (kW) | 130 kW |
Total Motor Power (Ps) | 177 Ps |
Total Motor Torque (N·m) | 300 Nm |
Front Motor Power (kW) | 130 kW |
Front Motor Torque (N·m) | 300 Nm |
System Combined Power (kW) | 240 kW |
System Combined Torque (N·m) | 530 Nm |
Number of Drive Motors | Single Motor |
Motor Layout | Front |
