741CFM Centrifugal Indoor Air Curtain For Restaurant
741CFM Centrifugal Indoor Air Curtain For Restaurant
741CFM Centrifugal Indoor Air Curtain For Restaurant
741CFM Centrifugal Indoor Air Curtain For Restaurant
Specifications
Brand Name :
NANYOO / OME / ODM
Model Number :
FM-4509H(B)-L(Y)-(MC)
Certification :
CE/CB/CCC/ ROHS
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiated
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
5000 per month .
Delivery Time :
30-35 work days
Packaging Details :
Carton With Foam Protection
Fan Type :
Centrifugal Flow
Product name :
Centrifugal Air Curtain / Door air barrier
Voltage :
220V-240V / 110V/60HZ
Control type :
Button / Remote control options
Material :
Full Metal housing
Color :
White , Options
Motor :
Pure copper motor warranty for 5 years
Application :
Restaurant ,Shopping Mall ,Coffee Shop ,Hotel
Description
Commercial Strong Wind Indoor Thin Centrifugal Door Air Barrier Full Metal Use For Restaurant

Door Air Barrier Features

Full metal housing with unique design / Air speed more than 14.5m / s .

Centrifugal style fan / Uniform forced airflow

3D Design Door Air Barrier Full Metal Casing White Color Suitable For Restaurant /
Warehouse / Shopping Mall / Coffee Shop/ Factories / Super market so on
741CFM Centrifugal Indoor Air Curtain For Restaurant

NANYOO AIR CURTAIN / The Real Air Barrier

Working principle : SAVING 90% ENERGY

Door Air curtain / Door air barrier also known as Air door , Air Barrier , widely used in Factories , Shops , Restaurants , Pharmacies ,

Cold storage , Hotels , Hospitals , Airports , Stations and other environments and all air-conditioned place .

Function Use the blower to generate a powerful airflow , effectively keep the indoor air clean , prevent air circulating

Indoor and Outdoor air , reduce energy consumption , prevent the intrusion of dust , insects and harmful gases

and provide a comfortable working , shopping and leisure environment . 741CFM Centrifugal Indoor Air Curtain For Restaurant

Precise motor , Strong air volume - 30 years of experience in motor R & D and manufacturing

Higher efficient motor

More energy saving

Longer service life

Using bigger core diameter , longer core lengh ,

Big stator slot dimensions and greater copper wire

And weight to increase efficiency

741CFM Centrifugal Indoor Air Curtain For Restaurant

Door Air Barrier -- Specification

Voltage/Frequency:220-240V/50Hz, or 110V/60Hz, 110V/50Hz, 220V/60Hz are all available.

Model Diameter of Impeller Input Power (W) Air
Velocity (m/s)		 Air Volume Noise Fuselage Size Mounting Height
(mm) H (m/s) (m³/h)/CFM (dB) (mm) (m)
FM-3509H(B)-L(/Y)(-MC) 120 230 14.5 1020/600 ≤44 900×235×215 3.0-3.5
FM-3510H(B)-L(/Y)(-MC) 120 230 14.5 1020/600 ≤44 1000×235×215 3.0-3.5
FM-3512H(B)-L(/Y)(-MC) 120 305 14.5 1360/800 ≤45 1200×235×215 3.0-3.5
FM-3515H(B)-L(/Y)(-MC) 120 385 14.5 1700/1000 ≤48 1500×235×215 3.0-4.5
FM-3518H(B)-L(/Y)(-MC) 120 460 14.5 2040/1200 ≤50 1800×235×215 3.0-3.5
FM-3520H(B)-L(/Y)(-MC) 120 460 18 20401200 ≤50 2000×235×215 3.0-3.5
FM-4509H(B)-L(/Y)(-MC) 120 330 18 1260/741 ≤46 900×235×215 4.0-4.5
FM-4510H(B)-L(/Y)(-MC) 120 330 18 1260/741 ≤46 1000×235×215 4.0-4.5
FM-4512H(B)-L(/Y)(-MC) 120 420 18 1680/988 ≤47 1200×235×215 4.0-4.5
FM-4515H(B)-L(/Y)(-MC) 120 545 18 2100/1235 ≤50 1500×235×215 4.0-4.5
FM-4518H(B)-L(/Y)(-MC) 120 635 18 2520/1482 ≤52 1800×235×215 4.0-4.5
FM-4520H(B)-L(/Y)(-MC) 120 635 18 2520/1482 ≤52 2000×235×215 4.0-4.5
FM-5509H(B)-L(/Y)(-MC) 120 440 21 1450/853 ≤48 900×235×215 5.0-5.5
FM-5510H(B)-L(/Y)(-MC) 120 440 21 1450/853 ≤48 1000×235×215 5.0-5.5
FM-5512H(B)-L(/Y)(-MC) 120 550 21 1930/1135 ≤49 1200×235×215 5.0-5.5
FM-5515H(B)-L(/Y)(-MC) 120 780 21 2420/1423 ≤52 1500×235×215 5.0-5.5
FM-5518H(B)-L(/Y)(-MC) 120 830 21 2900/1706 ≤54 1800×235×215 5.0-5.5
FM-5520H(B)-L(/Y)(-MC) 120 830 21 2900/1706 ≤54 2000×235×215 5.0-5.5

741CFM Centrifugal Indoor Air Curtain For Restaurant
