Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head
Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head
Specifications
Brand Name :
JOINT
Model Number :
B600
Certification :
ISO 9001:2015
Place of Origin :
China
MOQ :
1 SET
Price :
NEGOTIATION
Payment Terms :
T/T, L/C
Supply Ability :
30 SETS/MONTH
Delivery Time :
NEGOTIATION
Packaging Details :
Wooden pallet/ wooden case
Working table size :
1370*405mm
XYZ three axes travel :
1000/350/640mm
Spindle sleeve stroke :
150mm
Distance from spindle nose to table :
760mm
Spindle rotation speed :
3000rpm
Spindle motor :
5HP
Description

Introduction:

Compared with the normal turret milling machine, bed type milling machine is with bed structure, higher rigidity, and larger bearing capacity.

Its milling head is Taiwan original precision milling head, NSK ball screw, P4 precision spindle bearing, 0.002 spindle runout.

Suitable for heavy and large workpiece(800-1000kgs) processing.

Specification:

Model B600
Table size mm 1370*405
Travel X axis mm 1000
Y axis mm 350
Z axis mm 640
Travel of spindle quill mm 150
Maximum distance from spindle nose to table mm 760
Spindle Rotation speed
(Step speed milling head)		 50HZ rpm 58-3000
60HZ rpm 70-3600
Rotation speed
(Variable speed milling head)		 50HZ rpm 58-3250
60HZ rpm 70-3900
Rotation speed
(Inverter speed milling head)		 50HZ rpm 0-4200
60HZ rpm 0-4200
Taper NT40
Rated power HP 5HP
Tilt angle Forward and Backward 0°
Left and Right ±90°
Dimension mm 2000*2230*2150
Net weight kg 2800

Standard accessories:

1. Taiwan original step speed milling head
2. X/Y axis mechanical feed
3. Z axis elevator motor
4. Clamping kit
5. NT40 milling chuck
6. Working light
7. Draw bar
8. Oil pump
9. Manual operation
10. Guide way cover
11. Tool and tool box

Optional accessories:

Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head

Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head

Bed Type Turret Milling Machine B600 With Taiwan Original Precision Milling Head

Company Profile:

Shenzhen Joint Technology CO.,LTD., was established in 1995. One of our headquarters is located in PingHu town, Shenzhen City ,Guangdong province ,China, we are dedicating to research and development, production, sale, and service of mold processing machine tools and specialized machine tool equipments for machine work of excellent quality for more than two decades.
There are eight series of products-high speed turret milling machine, precision surface grinding machine, EDM machine tool, CNC milling machine, NC milling machine, Gantry type machine center, CNC engraving machine, and CNC lathe machine
Our own brand "JOINT " Has been the top quality machine's signal in domestic sales, JOINT also has been recognized as " GUANGDONG Famous Brand ", and milling machine was recognized as " TOP 10 Famous Brand of Milling machine " in China. Our product had been exporting to Europe, South America, Southeast Asia, the middle east etc, and enjoyed a good reputation there, Welcome your visit !
