Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
Specifications
Brand Name :
JOINT
Model Number :
818M
Certification :
ISO 9001:2015
Place of Origin :
CHINA
MOQ :
1 SET
Price :
NEGOTIATION
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SETS/YEAR
Delivery Time :
NEGOTIATION
Packaging Details :
WOODEN PALLTES / WOODEN CASE
Name :
Surface Gringding Machine
Spindle Rotation speed :
2800/50HZ
Table size :
460*200mm
X axis travel :
510mm
Y axis travel :
210mm
Guide way :
Slide way
Dimension :
1500*1220*2090mm
Net weight :
900kgs
Description

High cost performance high precision cost surface grinding machine 818M

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed

1. Flat-V guideway are adopt on longitudinal and cross way to get good guidance quality,and coat

with TURCITE-B belt,precision handscraping to keep stable wok accuracy.

2. Strengthen ribs are set inside of the rear slide base,make sure great stability support for spindle.

3. The machine bed and rear slide bed are assembled to one piece,to supply super strong base for

efficient working.

4. Hardened steel guide way and Taiwan rolling ball structure is adopt on X axis, with smoothly

motion,high accuracy and long life.

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed

Model 818M
Table size 460*200mm
Travel ( Longitude ) 510mm
Travel ( Crossward ) 210mm
Table side way Slide way
Max.distance from spindle center to working table 390mm
Crossward feed of hand wheel ( 1Rev ) 4
Crossward feed of hand wheel ( 1Div ) 0.02
Vertical feed of hand wheel ( 1Rev ) 1
Vertical feed of hand wheel ( 1Div ) 0.005
Rotation speed

2880rpm/50HZ

3360rpm/60HZ
Grinding wheel size Ø200*(6-20)*Ø31.75mm
Spindle motor 2*2
Vertical driven motor 0.12*2
Dust-clean motor 0.75*2
Coolant pump motor 0.12*2
Dimension ( L*W*H ) 1500*1220*2090mm
Net weight 900kg

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed

Blohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation SpeedBlohm Hydraulic Industrial Surface Grinder 2800rpm / 50Hz Spindle Rotation Speed
