Specifications
Brand Name :
Hengcheng
Model Number :
HVM2500 HVM2800 HVM3400 HVM4200 HVM4500 HVM4800 HVM5100 HVM5600
Certification :
ISO Patent Certificate High-Tech Product Certificate
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 sets/month
Delivery Time :
120 days
Packaging Details :
Standard shipping packaging
Type :
gypsum vertical mill
Video outgoing-inspection :
Provided
Capacity :
6-80 t/h
Core Components :
motor
Usage :
Grinding Mining Stone
Fineness :
80-400 Mesh
Grinding Way :
Dry Grinding
Installation :
Engineer Guide
Material :
Gypsum
Power :
22-185 kw
Description
20tph Gypsum Vertical Mill Coal Powder Cement Plant Gypsum Grinding Process In Vertical Mill
Gypsum Vertical Roller Mill
High Efficiency | Low Energy Consumption | Turnkey Solutions
Natural Gypsum Vertical Mill Advantage
✅ 42-45 μ m fineness - one-time grinding compliance rate ≥ 90%
✅ Reduce energy consumption by 40% - saving electricity compared to ball mills
✅ Moisture tolerance of 15% - integrated direct grinding and drying
✅ Environmental protection - the entire system has low vibration and noise; Overall sealing, full negative pressure operation, no dust overflow, basically achieving a dust-free workshop.

Specifications And Technical Parameters Of HVM Gypsum Vertical Mill

Model HVM2500 HVM2800 HVM3400 HVM3700 HVM4200 HVM4500 HVM4800 HVM5100 HVM5600
Grinding Table Median Diameter(mm) 2500 2800 3400 3700 4200 4500 4800 5100 5600
Capacity(t/h) 85-100 130-160 190-240 240-300 320-400 400-500 440-550 550-670 600-730
Raw Material Moisture ＜10%
Raw Meal Fineness R0.08＜12% R0.08＜14%
Raw Meal Moistrue ≤1%
Main Motor Power(kW) 800/900 1120/1250 1800/2000 2500/2800 3150/3350 3800/4200 4200/4500 5000/5400 5600/6000
Illustrate

Re:Raw materials bond index≤13kWh/t

20tph Gypsum Vertical Mill Coal Powder Cement Plant Gypsum Grinding Process In Vertical Mill

Working principle:

The material enters from the feed port of the mill and falls onto the rotating grinding disc. The grinding disc rotates under the drive of the transmission device, generating centrifugal force that moves the material towards the edge of the grinding disc. During the movement, the material is gradually crushed and ground by the rolling and grinding action of the grinding roller. At the same time, the hot air introduced from the bottom of the mill blows up the ground coal powder, forming a gas-solid two-phase flow. In the rising process, the pulverized coal is graded through the separator, and the qualified pulverized coal is discharged from the mill with the airflow and enters the subsequent pulverized coal collection system; Unqualified coarse powder is returned to the grinding disc under the action of gravity for further grinding.
20tph Gypsum Vertical Mill Coal Powder Cement Plant Gypsum Grinding Process In Vertical Mill20tph Gypsum Vertical Mill Coal Powder Cement Plant Gypsum Grinding Process In Vertical Mill

Application Showcase
✅ Architectural gypsum powder: α/β gypsum powder production line
✅ Desulfurized gypsum: resource utilization of by-products in power plants
✅ Phosphogypsum treatment: solid waste reduction in the fertilizer industry
✅ Overseas EPC projects: providing turnkey services from design to installation

Problem Solution Format for Customer Pain Points
❌ Traditional ball mills have high energy consumption → The power consumption of the vertical mill system is only 22-24kWh/t
❌ Moisture containing gypsum blocking equipment → patented air sweeping structure anti sticking wall design
❌ Instability in fineness control → Real time adjustment of roller pressure by hydraulic pressure system

FAQ
Q: What’s the difference between your mill and Raymond mill?
→ *A: 30% higher output & 50% less wear parts with roller-grinding technology*
Q: Can it connect with existing calcination system?
→ A: Yes! Flue gas duct & material feed chutes can be customized
Q: Do you provide wear parts replacement?
→ *A: Yes!
