ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
Specifications
Place of Origin :
Guangdong, China
Model Number :
JTT-1200R
Brand Name :
JINTONG
Packaging Details :
plastic film packing for rotary table vertical injection molding machine
Supply Ability :
600 Piece/Pieces per Month rotary table vertical injection molding machine
Price :
$32,000.00 - $40,000.00/pieces
Plastic Processed :
PP, ABS
Condition :
New
Style :
VERTICAL
Plasticizing Capacity(g/s) :
250
Mold Height(mm) :
150 - 520 mm
Ejector Number :
2
Ejector Stroke(mm) :
75 mm
Ejector Force(kN) :
27 kN
Theoretical Shot Volume(cm³) :
410 cm³
Injection Rate (g/s) :
202 g/s
Machine Type :
Hydraulic
Injection Weight (g) :
369 g
Screw Speed (rpm) :
1 - 220 rpm
Screw diameter (mm) :
50 mm
Screw L/D Ratio :
25
Distance between Tie Bars :
620mm
Weight (KG) :
5500 kg
Type :
Other
Open Stroke(mm) :
600 mm
Power (kW) :
24.5 kW
Warranty :
1 Year
Key Selling Points :
Multifunctional
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Pump, PLC, Pressure vessel
After-sales Service Provided :
Free spare parts
Product name :
rotary table vertical injection molding machine 120T
machine color :
grey blue
application :
spare parts on new enery vehicle
Marketing Type :
Ordinary Product
Port :
SHENZHEN
Description

ABS Plastic Processed 120T Hydraulic Rotary Table Vertical Injection Molding Machine

Product Description

Rotary table vertical injection molding machine JTT-1200R

Clamping Force: 120T

Injection Weight: 237-369g


Vertical clamping, vertical injection

Easy to set torque , speed, deceleration distance and stand number segmentation

Computer programme control rotary table direction , forward-rotating, reverse-rotating, forward and reverse alternative rotating.

Optional energy-saving motor

ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table

Main Features

1) vertical clamping, vertical injection,

2) clamping force, injection weight and shot speed can be changed according to actual demand.

3) 2 stations, 3 stations , multi-station(one up die, two or four down die), easy for operate insert parts, improve productivity

Certifications
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
Detailed Images
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
Our Service
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table
ABS Plastic Processed Hydraulic 120 Ton Injection Moulding Machine Vertical Rotary Table

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
