Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Specifications
Place of Origin :
Guangdong, China
Model Number :
JTT-1600R
Brand Name :
JINTONG
Packaging Details :
plastic film packing for rotary vertical injection molding machine 160T
Supply Ability :
400 Piece/Pieces per Month rotary vertical injection molding machine
Price :
$56,000.00/pieces 1-4 pieces
Plastic Processed :
PC, PVC, PA
Condition :
New
Style :
VERTICAL
Mold Height(mm) :
260 - 530 mm
Ejector Stroke(mm) :
75 mm
Ejector Force(kN) :
34 kN
Theoretical Shot Volume(cm³) :
570 cm³
Injection Rate (g/s) :
202 g/s
Plasticizing Capacity(g/s) :
400
Machine Type :
Hydraulic
Injection Weight (g) :
513 g
Screw Speed (rpm) :
1 - 155 rpm
Screw diameter (mm) :
55 mm
Screw L/D Ratio :
28
Distance between Tie Bars :
660mm
Weight (KG) :
7000 kg
Type :
screw injection
Open Stroke(mm) :
500 mm
Power (kW) :
22 kW
Warranty :
1 Year
Key Selling Points :
Multifunctional
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor, Pump, PLC, Pressure vessel
After-sales Service Provided :
Engineers available to service machinery overseas
screw diameter :
45cm 50cm 55cm
screw stroke :
240mm
Product name :
rotary table vertical injection molding machine JTT-1600R
opening force :
16.5T
rotary table diameter :
1400mm
max daylight :
600/660mm
min old height :
250/310mm
ejector force :
3.4T
Machine dimension(L*W*H) :
2.8*2.1*3.4m
Port :
SHENZHEN
Description
Product Description

Vertical rotary injection molding machine JTT-1600R

Clamping Force: 160T

Injection Weight: 344-513g


Vertical clamping, vertical injection

Easy to set torque , speed, deceleration distance and stand number segmentation

Computer programme control rotary table direction , forward-rotating, reverse-rotating, forward and reverse alternative rotating.

Optional energy-saving motor

Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R

Main Features

1) vertical clamping, vertical injection,

2) clamping force, injection weight and shot speed can be changed according to actual demand.

3) 2 stations, 3 stations , multi-station(one up die, two or four down die), easy for operate insert parts, improve productivity

Certifications
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Detailed Images
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Our Service
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R
Rotary Table Vertical 160 Ton Injection Moulding Machine JTT-1600R

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
