75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
Specifications
Place of Origin :
Guangdong, China
Model Number :
JTT-850R
Brand Name :
JINTONG
Packaging Details :
plastic film packing for plastic rotary table injection molding machine 85T
Supply Ability :
600 Piece/Pieces per Month plastic rotary table injection molding machine 85T
Price :
$30,500.00 - $38,000.00/pieces
Plastic Processed :
PC, ABS, PVC, PE
Condition :
New
Style :
VERTICAL
Plasticizing Capacity(g/s) :
180
Mold Height(mm) :
210 - 450 mm
Ejector Number :
2
Ejector Stroke(mm) :
75 mm
Ejector Force(kN) :
33 kN
Theoretical Shot Volume(cm³) :
275 cm³
Injection Rate (g/s) :
167 g/s
Machine Type :
Hydraulic
Injection Weight (g) :
250 g
Screw Speed (rpm) :
1 - 140 rpm
Screw diameter (mm) :
50 mm
Screw L/D Ratio :
24
Distance between Tie Bars :
560mm
Weight (KG) :
3600 kg
Type :
Other
Open Stroke(mm) :
500 mm
Power (kW) :
21.6 kW
Warranty :
1 Year
Key Selling Points :
High-accuracy
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Pump, Pressure vessel, Engine
Opening Stroke :
280MM
After-sales Service Provided :
Engineers available to service machinery overseas
screw diameter :
35mm 40mm 45mm
screw stroke :
190mm
Product name :
plastic rotary table injection molding machine 85T JTT-850R
opening force :
10.5T
rotary table diameter :
1180mm
max daylight :
500/560mm
min old height :
220/280mm
ejector force :
2.3T
Marketing Type :
Ordinary Product
Port :
SHENZHEN
Description

75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T

Product Description

Plastic rotary table injection molding machine 85T JTT-850R

Clamping Force: 85T

Injection Weight: 165-272g


Vertical clamping, vertical injection

Easy to set torque , speed, deceleration distance and stand number segmentation

Computer programme control rotary table direction , forward-rotating, reverse-rotating, forward and reverse alternative rotating.

Optional energy-saving motor

75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T

Main Features

1) vertical clamping, vertical injection,

2) clamping force, injection weight and shot speed can be changed according to actual demand.

3) 2 stations, 3 stations , multi-station(one up die, two or four down die), easy for operate insert parts, improve productivity

Certifications
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
Detailed Images
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
Our Service
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T
75mm Ejector Stroke Plastic Rotary Table Injection Molding Machine 85T

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
