85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
Specifications
Place of Origin :
Guangdong, China
Model Number :
JTT-850R
Brand Name :
JINTONG
Packaging Details :
plastic film packing for full-auto plastic vertical rotary injection molding machine
Supply Ability :
600 Piece/Pieces per Month full-auto plastic vertical rotary injection molding machine
Price :
$27,000.00/pieces 1-4 pieces
Plastic Processed :
PBT
Condition :
New
Style :
VERTICAL
Plasticizing Capacity(g/s) :
180
Mold Height(mm) :
110 - 450 mm
Ejector Number :
2
Ejector Stroke(mm) :
75 mm
Ejector Force(kN) :
33 kN
Theoretical Shot Volume(cm³) :
276 cm³
Injection Rate (g/s) :
167 g/s
Machine Type :
Hydraulic
Injection Weight (g) :
330 g
Screw Speed (rpm) :
1 - 200 rpm
Screw diameter (mm) :
50 mm
Screw L/D Ratio :
25
Distance between Tie Bars :
560mm
Weight (KG) :
4000 kg
Type :
Other
Open Stroke(mm) :
500 mm
Power (kW) :
21.6 kW
Warranty :
1 Year
Key Selling Points :
Energy saving
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, PLC, Pressure vessel
Opening Stroke :
280MM
screw diameter :
35mm 40mm 45mm
screw stroke :
190mm
Product name :
full-auto plastic vertical rotary injection molding machineJTT-850R
opening force :
10.5T
rotary table diameter :
1180mm
max daylight :
500/560mm
min old height :
220/280mm
ejector force :
2.3T
Clamping Force (kN) :
850 kN
Marketing Type :
Ordinary Product
Port :
SHENZHEN
Description

85t Full-Auto Vertical Rotary Injection Molding Machine 21.6 Kw Power 4000 Kg Weight

Product Description

full-auto plastic vertical rotary injection molding machine JTT-850R

Clamping Force: 85T

Injection Weight: 165-272g


Vertical clamping, vertical injection

Easy to set torque , speed, deceleration distance and stand number segmentation

Computer programme control rotary table direction , forward-rotating, reverse-rotating, forward and reverse alternative rotating.

Optional energy-saving motor

85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight

Main Features

1) vertical clamping, vertical injection,

2) clamping force, injection weight and shot speed can be changed according to actual demand.

3) 2 stations, 3 stations , multi-station(one up die, two or four down die), easy for operate insert parts, improve productivity

Certifications
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
Detailed Images
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
Our Service
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight
85T Fully Automatic Vertical Injection Moulding Machine 21.6Kw 4000Kg Weight

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
