30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
Specifications
Place of Origin :
Guangdong, China
Model Number :
JT-250 HS
Brand Name :
JINTONG
Packaging Details :
plywood case for 2021 new design vertical injection moulding machine 30T
Supply Ability :
600 Piece/Pieces per Month 2021 new design vertical injection moulding machine 30T
Price :
$9,600.00/pieces 1-2 pieces
Plastic Processed :
PP, ABS, PVC, PE
Condition :
New
Style :
VERTICAL
Plasticizing Capacity(g/s) :
60
Mold Height(mm) :
110 - 230 mm
Ejector Number :
1
Ejector Stroke(mm) :
35 mm
Ejector Force(kN) :
13 kN
Theoretical Shot Volume(cm³) :
85 cm³
Injection Rate (g/s) :
80 g/s
Machine Type :
Hydraulic
Injection Weight (g) :
72 g
Screw Speed (rpm) :
1 - 205 rpm
Screw diameter (mm) :
32 mm
Screw L/D Ratio :
22
Distance between Tie Bars :
340mm
Weight (KG) :
1100 kg
Type :
Other
Open Stroke(mm) :
280 mm
Power (kW) :
6.7kW
Warranty :
1 Year
Key Selling Points :
Competitive Price
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Pump, Pressure vessel
Injection Rate :
30-80CM3/S
Opening Stroke :
100MM
screw diameter :
20mm 25mm 30mm 32mm
screw stroke :
100mm
opening force :
6.5T
platen size :
520*370mm
max daylight :
280mm
After-sales Service Provided :
Free spare parts
After Warranty Service :
Video technical support
Marketing Type :
Ordinary Product
Port :
SHENZHEN
Description

30T Vertical Injection Moulding Machine With 13 KN Ejector Force And Low Maintenance

Related Products
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance

BMC machine

30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance

85T machine

30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance

small machine

Product Description

2021new design injection moulding machine 30T JT-250 HS

Clamping Force: 30T

Injection Weight: 29-72g

Vertical clamping, vertical injection

Small volum, suitablefor small and medium insert parts molding;

High shot pressure, fast shot rate, best choice for insert goods molding. Use famous brand accessories for electrical control and hydraulic system, low noise, precise, durable. Vertical screw injection system, multi-stage temperature control, multi-stage injection pressure and rate, back pressure adjustment, suitable for accurate plastic fittings molding.

Automatically display fault, easy to repair. Optional energy-saving motor; infrared safty device, automatic thermostatic device, leakproof spring nozzle, computer display, double proportion hydraulic controller.

get to contact information https://dgjintong.en.alibaba.com/contactinfo.html


30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance

Main Features

1) Vertical clamping, vertical injection, small volume, precise molding, available to small and medium hardware insert molding.
2)Vertical clamping,even pressure,accurate low-voltage protection,smooth injection and molding
3) Scalable computer programs, automatically removing, embedded devices, and other connections allow fully automatic operation of the whole machine.
4) Optional energy-saving motor

Certifications
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
Detailed Images
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance
Our Service
30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

30T Plastic Vertical Injection Moulding Machine 6.7kW With 13 KN Ejector Force Low Maintenance

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
