Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Specifications
Brand Name :
JINTONG
Model Number :
JTT-550 2V3R
Certification :
ISO9001 CE
Place of Origin :
Guangdong, China
Price :
$40,000.00 - $50,000.00/pieces
Supply Ability :
600 Piece/Pieces per Month Toothbrush making plastic injection molding machine JTT-550 2V3R
Packaging Details :
plastic film packing for Toothbrush making plastic injection molding machine JTT-550 2V3R
Plastic Processed :
PP, PVC, TPR
Condition :
New
Style :
VERTICAL
Ejector Stroke(mm) :
45 mm
Ejector Force(kN) :
13 kN
Theoretical Shot Volume(cm³) :
166 cm³
Injection Rate (g/s) :
70 g/s
Machine Type :
hydraulic
Injection Weight (g) :
150 g
Screw diameter (mm) :
30 mm
Distance between Tie Bars :
380mm
Weight (KG) :
3200
Type :
Other
Open Stroke(mm) :
320 mm
Power (kW) :
14.5 kW
Warranty :
1 Year
Key Selling Points :
high productivity
Applicable Industries :
Manufacturing Plant
Showroom Location :
None
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Pump, PLC, Pressure vessel
Opening Stroke :
180MM
screw diameter :
18mm 22mm 25mm
oil tank :
300L
Product name :
Toothbrush making plastic injection molding machine JTT-550 2V3R
rotary table diameter :
940mm
top platen size :
460*380mm
max daylight :
280/380mm
min old height :
100/200mm
ejector force :
1.3T
Clamping Force (kN) :
550 kN
After-sales Service Provided :
Video technical support, Free spare parts, Online support
After Warranty Service :
Video technical support, Online support, Spare parts
Local Service Location :
United States, Italy, France, Germany, Viet Nam, Brazil, Peru, Indonesia, India, Mexico, Russia, Thailand, Malaysia, Argentina, Colombia, Bangladesh, South Africa, Kazakhstan, Ukraine
Marketing Type :
Ordinary Product
Port :
SHENZHEN
Description

Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R

Product Description

Toothbrush making plastic injection molding machine JTT-550 2V3R


Clamping Force: 55T

Injection Weight: 68-90g

1. Vertical clamping, vertical injection, easy to change color or material, well mixed, rapid temperature rise
2. Different injection combination can be chosen to reach best productivity and less power loss according to different shot weight
3. One molding for dual-color/material embeded products, multi-sation rotary design, stable rotation, precise position, easy to put and pick out products
4. Injection system can be used individually
5. two color/material inject at the same time, suitable for all kinds of mold
6. samples: tooth brush, trademark, different kinds of accessories,handle of bicycle or electric vehicles

Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R

Main Features

Don’t ejector mold after finishing first injection system, and direct transfer to second injection system, and molding after second injection, without shrink or excessive glue
Optional automatic device for taking in or out to make unmanned automation equipment
Use special central shunt valve design, single direction rotary to avoid problems with water cooling lines.

Certifications
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Detailed Images
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Our Service
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.

Packing & Delivery
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R

Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
Toothbrush Handle Making Plastic Injection Molding Machine JTT-550 2V3R
