High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
Specifications
Brand Name :
JM
Model Number :
GSFM
Certification :
ISO9001,CE
Place of Origin :
Wuxi,China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
25 sets per mouth
Delivery Time :
15-45 days
Packaging Details :
Waterproof packaging
Controller :
Touch screen
Number of Cutterbars :
3 pcs
Colour :
Blue and white; Customizable
Drag chain :
Totally enclosed
Temper or not :
Yes
Controller position :
On the gantry; Customizable to separate
Description

High-Efficiency Fully Automatic Four Sided V Groove Cutter Machine for Door Industry and Aluminum Panel Processing

Safeguarding against trouble
Whether the production equipment always has high utilization rate and brings good economic benefits determines the competitiveness of an enterprise. Therefore, we always accompany you with our rich experience and technical strength to provide global service. When the equipment goes out of the factory, I will prepare the service item introduction for you, so that you can know the relevant information about the equipment maintenance in time, and be fully prepared to avoid and control the subsequent expenditure.

Keep all functions of the standard model
Automatic calculation of internal and external diameters, automatic cycle programming, visual picture editing, bending effect display, tool holder self-lubricating system, intermittent working hydraulic station, etc.

One-time forming of workpiece
The workpiece no longer needs to be shifted manually, which greatly improves the dimensional accuracy, saves labor costs, saves time costs and improves production efficiency.

No. Name Parameter Unit
1 Max. Width of metal sheet 1500 mm
2 Max. Length of metal sheet 4000 mm
3 Max. thickness(Stainless steel) 5 mm
4 Min. Thickness of metal sheet 0.4 mm
5 Min.distance of the V from edge 12 mm
6 Max. cutting speed of X axis 120 m/min
7 Max .return speed of X axis 120 m/min
8 Max.distance of Y axis 1250 mm
9 Resolution in Y axis 0.001 mm
10 Repeated positioning accuracy ±0.01 mm
11 Resolution in z axis 0.001 mm
12 Repeated positioning accuracy ±0.01 mm
13 Motor power X axis 5.5 kW
U 3.0
Y1,Y2,Z axis 1.0
14 Overall dimension Length 5980 mm
Width 2420
Height 1600

High Efficiency V Groove Cutter Machine Automatic For Aluminum Panel Processing
