Specifications
Brand Name :
ASLI
Model Number :
ES-50
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD 20000~50000
Payment Terms :
T/T
Supply Ability :
30 set per month
Delivery Time :
30-35 work days after deposit
Packaging Details :
export standard plywood case
sine force :
50000N
speed :
2.0m/s
displacement :
100mm
frequency :
1~3500HZ
loading :
750kg
Acceleration :
100g
armature :
450mm
Brand :
ASLI
Table Size :
800x800mm
Description

EC60068 High Frequency Electrodynamic Shaker Vibration Shaker System

Electrodynamic Vibration Shaker System Random Sine and Shock Function

Electrodynamic Vibration Shaker System Random Sine and Shock Function is widely used in defense, aviation, aerospace, communications, electronics, automobiles, home appliances, and other industries. This type of equipment is used for discovering the early faults, simulating the actual working condition and the structure strength test, the product application is wide, the application width is obvious, the test effect is remarkable and reliable. Sine wave, FM, sweep, programmable, frequency multiplier, logarithm, maximum acceleration, amplitude modulation, time control, full function computer control, simple fixed acceleration/fixed amplitude. Equipment through continuous failure to run 3 months of testing, stable performance, reliable quality.

Shaker Specifications
Peak Sine (Pk) 5000Kg.f peak (50KN)
Random (RMS) 5000Kg.f r.ms (50KN)
Shock (Pk) 10000Kg.f peak (100KN) @6ms
Usable Frequency 1～2500Hz
Maximum Displacement (p-p) 100mm (4 inch) , 76mm (3inch) continuous
Max. velocity 2m/s
Max. acceleration Sine:100g (980 m/s2), Random 62g(600 m/s2)
Vertical Load Support 500 kg

Body Suspension Natural

Frequency (Thrust Axis)

 Less than 2.5 Hz
Armature Diameter Ф440 mm
Armature Weight 59kg

Fundamental Resonance

Frequency (Bare table)

 2,400 Hz (nom.) +/- 5%

Load Attachment

Points (Standard)

 16 stainless steel M10 Inserts
Stray Flux Density ＜10 gauss
Shaker dimensions 1670mmL×1150mmD×1300mmH
Weight of Shaker About 4600Kg
Compressed Air Requirement 0.6 Mpa

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

More Specification

Name Automobile Battery EN50604 IEC62133 UN38.3 Vibration Test Bench for Lab testing
Model Rated Sine Force (N) Rated Random Force (N) Frequency Range (Hz) Rated Acceleration (m/s2) Rated Speed(m/s) Rated displacement (p-p)mm Max. Loading (Kg) moving coil (Kg) Dimension of Moving coil (mm)
ES-6 6000 6000 3-3500 1000 1.6 25 180 6.5 Φ230
ES-6a 6000 6000 3-3500 1000 1.6 51 250 12 Φ230
ES-10 10000 10000 3-3000 1000 1.8 51 270 14 Φ240
ES-20 20000 20000 3-3000 1000 1.8 51 300 30 Φ320
ES-30 30000 30000 3-2800 1000 1.8 5l 450 40 Φ450
ES-40 40000 40000 3-2800 1000 1.8 51 500 50 Φ450
ES-50 50000 50000 3-2700 1000 1.8 51 750 50 Φ450
ES-60 60000 60000 3-2700 1000 1.8 51 750 60 Φ450
ES-100 100000 100000 3-2500 1000 1.8 51 1000 90 Φ450

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 StandardHigh Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard

1. Well-designed dynamic circle skeleton, with a higher stage axial resonance frequency.

2. Two-magnetic circuit, magnetic flux leakage low, compact structure and rational.

3. Rocker Rod roller bearings straight and import-oriented composite body stiffness orientation, eccentric load capacity.

4. Trunnion isolation foundation dedicated to hormone use, the installation of mobile convenience.

5. Advanced technology move around the system to ensure that the dynamic circle of high reliability.

6. New duct design and enhance the cooling effect.

7. Static stiffness, dynamic stiffness of the bearing small balloon, raising the vibration table bearing capacity, improve low-frequency performance.
High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard
High Frequency 50000N Electrodynamic Vibration Shaker IEC60068 Standard
