ISO Standard Bump Tester Machine For Electronic Products Shock Testing
ISO Standard Bump Tester Machine For Electronic Products Shock Testing
ISO Standard Bump Tester Machine For Electronic Products Shock Testing
ISO Standard Bump Tester Machine For Electronic Products Shock Testing
Specifications
Brand Name :
LABTONE
Model Number :
SKM1500
Certification :
CE ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
15 Sets / Month
Delivery Time :
40 working days
Packaging Details :
international wooden case
Product Name :
Bump Tester Machine
Payload :
1000kg
Wave Form :
Haf sine pulse
Acceleration Range :
5-60 G
Pulse Duration :
6-18ms
Bump Repetition Frequency :
1-80
Drop Height Range :
5-180mm
Max Velocity Variation :
2.8m/s
Table Size :
1500*1500 mm
Description

ISO Standard Bump Tester Machine For Electronic Products Shock Testing

Applicable areas

Components and other electronic and electrical products may experience repeating impact during transportation or use. Bump test can be used as a method to ensure the design structure is satisfying or as a quality assurance method. Specimen will experience regular peak acceleration and continuous impact with standard pulse during the bump test.

Speicifications

Model SKM700 SKM800 SKM1000 SKM1500
Table size(mm) 700*800 800*800 1000*1000 1500*1500
Payload(kg) 100 200 500 1000
Wave form Half sine pulse
Acceleration range(G) 5-100 5-100 5-80 5-60
Pluse duration(ms) 6--18
Bump repetition frequency 1-120 1-120 1-80 1-80
Drop height range 5-120mm 5-120mm 5-180mm 5-180mm
Max velocity variation 2.2m/s 2.6m/s 2.8m/s 2.8m/s
Machine dimension(mm) 900*900*800 900*960*800 1200*1150*860 1600*1650*1200
Machine weight(kg) 1260 2160 3660 6500
Power & Air supply AC220V ±10% 50Hz Air supply:8kg 23m3 gasholder
Standards GB/T2423.4,GB/T2423.6, IEC68-2-29, JJG497-2000, JISC0042-1995 etc

Packaging & Shipping

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case,which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless,moisture corrosion, good transparency etc

Services

Presales:

  • Technical consultation: test method, laboratory planning and suggestion.
  • Equipment selection: selection scheme, FAQ.
  • Product testing scheme.

In-Sales:

  • Customer communication and progress report.
  • Guidance for pre-installation preparation, equipment commissioning and test run.
  • Calibration (when Third Party’s verification is required).

After-Sales:

  • Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.
  • Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.
  • Technical support: special paid services are provided according to customer’s needs.

Factory

ISO Standard Bump Tester Machine For Electronic Products Shock Testing
