Dynamic Shaker Vibration Testing Machine For Product Reliability Testing
Dynamic Shaker Vibration Testing Machine For Product Reliability Testing
Dynamic Shaker Vibration Testing Machine For Product Reliability Testing
Dynamic Shaker Vibration Testing Machine For Product Reliability Testing
Dynamic Shaker Vibration Testing Machine For Product Reliability Testing
Dynamic Shaker Vibration Testing Machine For Product Reliability Testing
Specifications
Brand Name :
LABTONE
Model Number :
EV203
Certification :
CE / ISO
Place of Origin :
Dongguang, China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
15 Sets / Month
Delivery Time :
45 Working Days
Packaging Details :
Plywood Case with Vacuum Packing
Max. Sine Force :
300 kg.f
Max. Random Force :
300 kg.f
Max. Shock Force :
600 kg.f
Max. Acceleration :
100G
Max. Velocity :
120cm/s
Max. Displacement :
38 mm
Description

Dynamic Shaker Vibration Testing Machine For Product Reliability Testing

Features:

  1. Strength of the suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability.
  2. Perfect performance on amplitude variation.
  3. High efficient on D Class power conversion, 3 - Sigma peak current, provide the optimization of power consumption and minimum harmonic distortion.
  4. U-type spring ,rollers and linear bearing for strong resistance of deflecting load
  5. Able to complete sine ,random , impact environmental tests
  6. High reliability, especially suitable for long-time operation
  7. Quick self-diagnosis with safety interlock, high safety reliability;
  8. High efficient on D Class power conversion, 3 - Sigma peak current, provide the optimization of power consumption and minimum harmonic distortion.

Applicable Standards:

MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.


Applicable Industries:

Automotive, Electronics, Aerospace, Vessel, Telecommunication, Optoelectronics, Instrument etc.

Specifications: EV103-EV220

Model EV103 EV203 EV106 EV206 EV210 EV220
Vibration Generator VG300/25 VG300/40 VG600/25 VG300/50 VG1000/50 VG2000/50
Frequency(Hz) 2-4000 2-2500 2-3000 2-3000 2-3000 2-2500
Max Exiting Force(kg.f) 300 300 600 600 1000 2000
Max. Displacement (mmp-p) 25 38 25 50 50 50
Max. Acceleration(g) 100 100 100 100 100 100
Max. Velocity(cm/s) 200 120 180 200 200 200
Payload(kg) 110 120 200 200 300 400
Armature Mass(kg) 3 3 6 6 10 20
Armature Diameter(mm) φ150 φ150 φ200 φ200 φ240 φ320
Cooling Method Forced Air Cooling
Vibration Generator Weight(kg) 460 460 720 920 1100 1600
Vibration Generator Dimension L*W*H(MM) 750*560*670 750*555*670 800*600*710 800*600*710 845*685*840 1200*870*1100
Power Amplifier Amp3k Amp3k Amp6k Amp6k Amp12k Amp22k
Cooling Method Forced Air Cooling
Power Amplifier Weight(kg) 250 250 320 320 350 500
Power Amplifier Dimension L*W*H(MM) 800*550*1250 800*550*1250 800*550*1250 800*550*1250 800*550*1520 800*550*1520
Utility
Requirements		 3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW) 8 9 18 20 25 35

Equipment Configuration:

Item Configuration Qty.
1. Vibration Shaker
VG300-40 electromagnetic vibration generator 1 set
BL-300 cooling blower (including silencer) 1 set
Vertical table 1 set
Automatic centering system of armature 1 set
2. Digital switch power amplifier
Amp3K digital switch power amplifier 1 set
Servo protection system 1 set
Excitation power supply 1 set
3. Digital vibration controller (integrated instrument cabinet)
Master unit of digital vibration controller 1 set
System acceleration sensor 1 pcs
Control computer 1 set
Control software installation disc 1 set
4. Attached accessories
Extension cable and duct hose 1 set
Operation instructions, inspection report, certificate, maintenance manual, etc. 1 set
Attached special tools 1 set
Vibration press rod / holddown strip fixture 1 set

Our Services:

Service commitment and support
Pre-sales service Technical Advisory;
Equipment Selection;
Product testing scheme.
In-sales service Close and effective communication with clients;
Timely and effectively solve the related issues.
After-sales service Warranty period of one year ;
Equipment installation and debugging;
Technical training;
Feedback within 2 hours after get the call.
Others Maintenance, modification and upgrade for the machine;
Design and producing for special fixtures and table
