IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
Specifications
Brand Name :
LABTONE
Model Number :
SKT50
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1SET
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15 Sets / Month
Delivery Time :
45 working days
Packaging Details :
International wooden case
Table Size :
50*60（CM）
Max. specimen weight :
50 kg
Max. acceleration :
Half sine: 600G
Machine Dimension :
130*120*260 (cm)
Controller cabinet Dimension :
W55*D50*H80 (cm)
Machine Weight :
3200 (Kg)
Name :
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
Description

IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test​

Product description

Products are inevitably affected by impact, bump, free fall, tumbling, etc. during production, transportation, loading and unloading as well as during the use of the products. All of these are transient excitation on the object, causing the object to produce mechanical characteristics of high speed, acceleration, strain rate, etc instantly. These kind of characteristics are completely different from that in static load, and may cause problems to the object in terms of structural strength and stability and sometimes the object may fail. Therefore, it is necessary to study the effect of impact and reproduce the shock environment, to assess the structural strength and performance of the object under shock environment.

Mechanical Shock Test Equipment Specifications

Model SKT30 SKT50 SKT100 SKT200 SKT300 SKT600 SKT1000
Table size (cm) 40*40 50*60 70*80 100*100 120*120 150*150 200*200
Maximum Specimen Weight(Kg) 30 50 100 200 300 600 1000
Max acceleration(G) half sine 600 600 600 500 500 300 300
saw-tooth waveform 100 100 100 100 100 100 100
square 150 150 150 150 100 100 100
Pulse Duration (ms) half sine 40—0.2 40~1 40~1 30~2 20~3 20~3 20~3
saw-tooth waveform 18~6 18~6 18~6 18~6 18~6 18~6 18~6
square 30~6 30~6 30~6 30~6 30~6 30~6
Machine Dimension(cm) 120*110*245 130*140*260 130*120*260 150*130*260 200*160*300 230*180*310 250*220*310
Controller cabinet Dimension(cm) W55*D50*H80
Machine Weight(Kg) 1900 2300 3200 4200 8500 15500 19500
Utility 3-phase AC380V 50/60Hz 0.5~0.8MPa
Requirements
Conforming standards GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL

Mechanical Shock Test Equipment Applications:

Shock test is used to accurately measure the product fragility and evaluate the protective ability of product packaging. To do a boundary assessment on complete product breakage, industrial standard shock pulse or company’s internal standards, we can provide the most advanced shock test system to meet your application requirements.

Suitable shock tests for aviation, aerospace, marine, military, consumer electronics, automobiles, home appliances and display devices.

By selecting different waveform generators, it can perform half sinusoidal wave, sawtooth wave, or trapezoidal wave.

Mechanical Shock Test Equipment Services

Presales:

  • Technical consultation: test method, laboratory planning and suggestion.
  • Equipment selection: selection scheme, FAQ.
  • Product testing scheme.

In-Sales:

  • Customer communication and progress report.
  • Guidance for pre-installation preparation, equipment commissioning and test run.
  • Calibration (when Third Party’s verification is required).

After-Sales:

  • Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.
  • Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.
  • Technical support: special paid services are provided according to customer’s needs.
IEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack TestIEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack TestIEC 62133 Mechanical Shock Test Equipment Shock Tester For Battery Pack Test
