Strong Carrying Capacity Vibration Test System For Televisions Vibration Test
Strong Carrying Capacity Vibration Test System For Televisions Vibration Test
Strong Carrying Capacity Vibration Test System For Televisions Vibration Test
Strong Carrying Capacity Vibration Test System For Televisions Vibration Test
Specifications
Brand Name :
LABTONE
Model Number :
EV330
Certification :
CE / ISO
Place of Origin :
Dongguang, China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
15 Sets / Month
Delivery Time :
45 Working Days
Packaging Details :
Plywood Case with Vacuum Packing
Product Name :
Vibration Testing System
Max Sine Force :
30KN
Max Displacement :
76mmp-p
Max. Acceleration :
85G
Max. Velocity :
200cm/s
Max Load :
1000kg
Frequency Range :
2-2500Hz
Description

Vibration Testing System For Televisions Vibration Test Meet GJB Requirements

Applicable Standards: MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.


Applicable Industries: Automotive, Electronics, Aerospace, Vessel, Telecommunication, Optoelectronics, Instrument etc.


Features:

  • Strength of the suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability.
  • Perfect performance on amplitude variation.
  • High efficient on D Class power conversion, 3 - Sigma peak current, provide the optimization of power consumption and minimum harmonic distortion.
  • Rapid self-test diagnostics and chain safeguard, high high safety and reliability
  • Air gasbag isolation damping device realize the the vibration table with no need for special foundation. Perfect reappearance vibration waveform and the reduction of vibration transmission
  • Different application on the vertical and horizontal tables.
  • Simple operation for the controller.

Specifications: EV240-EV330

Model EV240 EV250 EV260 EV320 EV330
Vibration Generator VG4000/50 VG5000/50 VG6000/50 VG2000/76 VG3000/76
Frequency(Hz) 2-2500 2-2500 2-2500 2-3000 2-2500
Max Exiting Force(kg.f) 4000 5000 6000 2000 3000
Max. Displacement (mmp-p) 50.8 50.8 50.8 76 76
Max. Acceleration(g) 100 100 100 80 85
Max. Velocity(cm/s) 200 200 200 200 200
Payload(kg) 800 1000 1000 1000 1000
Armature Mass(kg) 40 50 50 25 35
Armature Diameter(mm) φ400 φ450 φ450 φ320 φ320
Cooling Method Forced Air Cooling
Shaker Weight(kg) 2500 3500 3800 2000 3000
Shaker Dimension L*W*H(MM) 1400*980*1100 1600*1120*1340 1600*1120*1340 1400*980*1100 1600*1120*1340
Power Amplifier Amp50k Amp60k Amp70k Amp50k Amp60k
Power Amplifier Weight(kg) 600 800 1000 550 600
Power Amplifier Dimension L*W*H(MM) 800*550*1920 800*550*1920 800*550*1920 800*550*1920 800*550*1920
Utility
Requirements		 3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW) 64 85 95 40 60

Horizontal oil film slip table


The horizontal slip table is designed to have high tilting moment and lateral restriction. This design concept is combined with standard horizontal slip table to enable high dynamic moment limit and keep guide oil film damping feature. The horizontal slip table is composed of a slipper, a connector, a natural granite slab, horizontal slip table base and an independent oil source.

Strong Carrying Capacity Vibration Test System For Televisions Vibration Test

Our Services

Pre-Sales Service

1)Technical consultation: test method, laboratory planning and suggestion.

2)Equipment selection: selection scheme, FAQ.

3)Product testing scheme.

4)Customer communication and progress report.

After-Sales Service

1)Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.

2)Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.

3)Technical support: special paid services are provided according to customer’s needs.

Details

Strong Carrying Capacity Vibration Test System For Televisions Vibration Test
