grain cleaning machine, grain machine for remove the moldy, dust and coarse

Product Description:

The HYL-25 series grain cleaning machine, grain machine for remove the moldy, dust and coarse is one kind of multiple and economical grain cleaning and screening machine for grain depot. It is mainly applied for the seed cleaning sorting and grading of wheat, barley, corn, bean, paddy ,rice, cotton seed,camellia and so on.

It is to clean dust, leaf, coarse light impurity husk and separate or sort the grain/seed to three grades: big size, medium size and small size. This machine can separate the stone different size with grain/seed, but can not remove the same size ones with grain or seed.

Product Structure

1. Dust removing blower 2.Observation hole 3.Plate

4. Adjust the air pressure 5.Adjust the propotion of screen volume 6.Vibrating Motor

7. Adjust the height 8. Finished grain outlet

9. Coarse cereals outlet 10. Main air blower 12. Separation platform

Working Procedure

1st procedure for impurities removing and separation: Forced by the gravity and vibration, the grain materials is forward to the 1st screening surface for sieving and grading, and the impurities is backword to the impurities outlet.

2nd procedure for grain and impurities separation: The grain particles is sieved from 1st screen surface to the 2nd surface. The hole size of screen mesh is equal to the grain particle size, in this case, the small impurities and the broken grains will be sieved to the 3rd screen surface,the refined grain particles will forward to the finished product outlet for packing or conveying to the grain depot.

3rd procedure for tiny impurities and broken grain separation: The hole size of the 3rd mesh is only for passing the tiny impurities and food debris and then to the impurities outlet. And the small grain particles will forward to the outlet for bagging.

Technical Data
