high quality low price mobile conveyor belt
high quality low price mobile conveyor belt
Specifications
Place of Origin :
China
Brand Name :
OEM,ODM,YUZHEN
Certification :
CE,ISO
Model Number :
DY4031
Material :
Rubber
Material Feature :
Heat Resistant
Structure :
Belt Conveyor
Condition :
New
Load Capacity :
90m3/h or 80 ton/h
MOQ :
1 SET
Price :
500USD
Packaging Details :
IN STANDARD WOODEN BOX
Delivery Time :
1-15 DAYS AFTER GETTING THE DEPOSIT
Payment Terms :
TT,LC,WESTEN UNION
Supply Ability :
500 SETS/MONTH
Type :
Mobile belt conveyor
Description
high quality low price mobile conveyor belt
——welcome

Ⅰ Product Description
DY mobile belt conveyor is a kind of continuous mechanical handing equipment with high efficiency, good safety and good mobility. Mainly used for short-distance transport, handing of bulk material and the product one-piece weight less 100kg on loading and unloading stations which are often changed, such as the port, terminal, station, coal yard, warehouse, building site, sand quarry, farm and so on. It can be divided into lift and not lift type, the running of belt is driven by electric-roller, and the whole lifting and running are non-motorized.
DY mobile belt conveyor used for bulk material and product’s short-distance transport and loading work. It adopts the tubular structure, lightness and good mobility. The rotation device is electric-roller, and equipped with two wheels, pneumatic tires and steel-wheel. The machine body length more than 10 meters and the angle can be adjusted.

Ⅱ Product Features
The belt conveyer can be widely applied to the bulk material and packaged items in departments like coal, metallurgy, chemical engineering, hydroelectricity, traffic, building material and so on. Its performance and main technical parameters are equal to Germany Flender and Thyssen company's products.It can be used for not only horizontal conveying, but also inclining conveying in which there is inclination and uneven segment. With simple structure, high precision and long lifetime, it is used conveniently and universally.
Note:The conveying amount in the table is formulated on the condition that the material’s specific weight r=1 t/m3 , the conveyer’s inclining angle is 0~7°, and the angle of repose is 30°
Redesign for customer’s special demand is available.

Ⅲ Technical parameters


Sheet 1

Item

DY4031

DY4051

DY4071

DY10101

Length(m)

3

5

7

10

Bandwidth(mm)

400

400

400

400

Tape speed(m/s)

1.6

1.6

1.6

1.6

Max delivery height(m)

1.2

1.2

1.3

1.29

Conveying capacity

m3/h

90

90

90

90

t/h

80

80

80

80

Angle of repose(°)

17°

10°

8°

5°58′

Electric-roller

Type

DY1.2

DY1.2

DY1.2

DY1.2

Power
(KW)

1.5

1.5

1.5

1.5

Total-weight(kg)

320

391

467

592


Sheet 2

Item

DY5051

DY5071

DY50101

DY50102

DY50102A

DY50151

DY50152

DY50152A

Length(m)

5

7

10

10

10

15

15

15

Bandwidth(mm)

500

500

500

500

500

500

500

500

Tape speed(m/s)

1.6

1.6

1.6

1.6

1.6

1.6

1.6

1.6

Max delivery height(m)

1.63

1.59

1.77

4.52

4.52

1.61

6.32

6.32

Conveying
capacity

m3/h

160

160

160

125

125

160

125

125

t/h

145

145

145

112

112

145

112

112

Angle of repose(°)

13°59′

9°16′

6.5°

10°～22°

10°～22°

3.81°

10°～22°

10°～22°

Electric-
roller

Type

DY1.4

DY1.4

DY1.4

DY1.5

DY1.3

DY1.4

DY1.6

DY1.3

Power(KW)

2.2

2.2

2.2

3.0

1.1

2.2

4.0

1.1

Total-weight(kg)

518

604

892

1126

1071

1225

1491

1491


Sheet 3

Item

DY6551

DY6571

DY65101

DY65102

DY65102A

DY65151

DY65152

DY65152A

Length(m)

5

7

10

10

10

15

15

15

Bandwidth
(mm)

650

650

650

650

650

650

650

650

Tape speed
(m/s)

1.6

1.6

1.6

1.6

1.6

1.6

1.6

1.6

Max delivery
height(m)

1.55

1.52

1.82

4.56

4.56

1.85

6.48

6.48

Conveyng
capacity

m³/h

290

290

290

224

_

290

224

_

t/h

265

265

265

200

200

265

200

200

Angle of repose(°)

13°29′

8°53′

6.5°

10°～22°

10°～22°

4.32°

10°～22°

10°～22°

Electric-roller

Type

DY1.9

DY1.9

DY1.10

DY1.11

DY1.8
