Automatic unloading grain of the gravitational force screw conveyor
Automatic unloading grain of the gravitational force screw conveyor
Specifications
Brand Name :
hongyuan
Model Number :
XL-6, 8, 10, 12
Certification :
ISO
Place of Origin :
Henan, China
MOQ :
1 Set
Price :
USD 650~1150 Set
Payment Terms :
T/T,Alibaba Trade Assurance
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
Shipped in 2 days after payment
Packaging Details :
In standard ply wood boxes
Name :
the gravitational force screw conveyor
Condition :
New
Usage :
Automatic type
Type :
Screw Conveyor
Material :
PVC
Load Capacit :
5-15T/h
Voltage :
Requirement, 220v/380v
Power(W) :
3-4 KW
Color :
customization
Description
Automatic unloading grain of the gravitational force screw conveyor

Product Description

Automatic unloading grain of the gravitational force screw conveyor is a new designed for grain suction, entrucking, stack transfer and storage in village.

It has the features of small area, light weight, easy movable, high effeciency and low rate of brokage. the small suction machine is widely used for many places with safty and relibality. such as individual farmer, grain professional farmers and agricultural cooperativies.

Automatic unloading grain of the gravitational force screw conveyor

Detailed Images

Structure of screw elevating conveyor

  • Screw flight: the material of screw flight is manganese steel, it has good wear-resisting and flexible.
  • Wear-resisting pipe: The material of screw pipe is PVC resin, the PVC resin screw pipe is very good wear-resisting pipe, this will prolong the service lift of screw elevating conveyor.
  • Driving device: Motor, belt pulley, transmission belt and safe cover.
  • Inlet device and discharge device.

Automatic unloading grain of the gravitational force screw conveyor

Automatic unloading grain of the gravitational force screw conveyor

Product Features & Procedure

Small and easy-to-operate material handling conveyor for cereal is easy to carry and operated and is one convenient portable grain inhaling suction equipment.

  • It has the feature of small volume, large power, convenient to carry.
  • The power source can adopt the single phase which is applied for home use.
  • Man power saving ideal machine for truck loading.
  • Large capacity at 10-15 ton/h
  • Customized length is supported(6meters,8meters,10meters is available)
  • Lifting height is 3 meters

Automatic unloading grain of the gravitational force screw conveyor

Automatic unloading grain of the gravitational force screw conveyor

Automatic unloading grain of the gravitational force screw conveyor

packing and delivery

Automatic unloading grain of the gravitational force screw conveyor

Automatic unloading grain of the gravitational force screw conveyor

Technical Data

Model No. Length (Meters) Pipe diameter

Loading

Capacity(t/h)

 Motor phase-power(kw) Installation Structure Conveying height
XL-100- 6 6 100mm 5-8 Single phase-220V-3kw Vehicle mounted Steel screw blade inside 3-4m
XL-100- 8 8 100mm 5-8 Single phase-220V-3kw Vehicle mounted Steel screw blade inside 3-4m
XL-100- 10 10 100mm 5-8 Single phase-220V-3kw Vehicle mounted Steel screw blade inside 3-4m
XL-100- 12 12 100mm 5-8 Single phase-220V-3kw Vehicle mounted Steel screw blade inside 3-4m
XL-160- 6 6 160mm 15-20 Three phase-220V-4kw Vehicle mounted Steel screw blade inside 3-4m
XL-160- 8 8 160mm 15-20 Three phase-220V-4kw Vehicle mounted Steel screw blade inside 3-4m
XL-160- 10 10 160mm 15-20 Three phase-220V-4kw Vehicle mounted Steel screw blade inside 3-4m
XL-160- 12 12 160mm 15-20 Three phase-220V-4kw Vehicle mounted Steel screw blade inside 3-4m

Matters need attention

  • Three phase motor cannot reverse running

  • Please do not let the machine running without loading

  • Please do let the machine running with loading

  • Please do not let the machine do the idling running
