Customizable Vacuum Conveyor Vertical Transport Powder Conveying Equipment
Customizable Vacuum Conveyor Vertical Transport Powder Conveying Equipment
Customizable Vacuum Conveyor Vertical Transport Powder Conveying Equipment
Customizable Vacuum Conveyor Vertical Transport Powder Conveying Equipment
Specifications
Brand Name :
EVERSUN MACHINERY
Model Number :
QVC/XK
Certification :
ISO,CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
5000SETS/YEAR
Delivery Time :
within 7-15 work days
Packaging Details :
Standard export wooden package
Name :
Powder Conveying Equipment
electronic control system :
Control box /PLC/ control cabinet
Delivery(kg/h) :
customized
Material :
Carbon steel,SUS304/316L
Application :
Powder, Particle
Advantage :
Support non-standard customization
Description

Product introduction

Customizable Vertical Transport Powder Conveying Equipment Vacuum Conveyor

As a powder conveying equipment, vacuum conveyor can meet the production requirements of rapid and mass processing, thus saving labor costs and improving the production efficiency of the factory. At the same time automatic feeding is an essential equipment in modern industrial operations, mainly applicable to chemical, metallurgy, construction, pharmaceutical and other light industry and heavy industry and other fields.

Vacuum conveying equipment is divided into many types, according to the different power sources can be divided into pneumatic vacuum conveyor and electric vacuum conveyor. Among them, the main difference between the pneumatic vacuum conveyor and the electric vacuum conveyor is the size of the volume and the power source. According to the discharge method, it can be divided into intermittent vacuum conveyor and continuous vacuum conveyor. The intermittent vacuum conveyor uses the flip valve to discharge, while the continuous vacuum conveyor uses the rotary valve to continuously discharge.

Product parameters

Pneumatic vacuum conveyor:

Model QVC-1 QVC-2 QVC-3 QVC-5
Delivery(kg/h) 50-300 100-700 300-1500 600-3000
Warehouse volume(L) 1.1 6.0 12.0 42
Operating pressure(Mpa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6
Compressed air consumption(N/min) 180 360 720 1440
Machine can be customized according to your needs

Electric vacuum conveyor:

Model XK-1 XK-2 XK-3 XK-4 XK-5 XK-6 XK-7
Capacity 600L/h 600L/h 1200L/h 2000L/h 3000L/h 4000L/h 6000L/h
Power 1.6kw 2.2kw 3kw 4.0kw 5.5kw 5.5kw 7.5kw
gas consumption 8L/min 8L/min 10L/min 12L/min 12L/min 12L/min 17L/min
Air pressure 0.5-0.6mpa 0.5-0.6mpa 0.5-0.6mpa 0.5-0.6mpa 0.5-0.6mpa 0.5-0.6mpa 0.5-0.6mpa

Customizable Vacuum Conveyor Vertical Transport Powder Conveying Equipment

Product feature

1. Intermittent vacuum conveyor is usually small conveying output, conveying distance is not more than 10 meters, for small production; Continuous vacuum conveyors can be used for long distance and large output transportation.

2. The pneumatic vacuum conveyor is small in size and occupies a small area. The power source is provided by its own vacuum generator, while the electric vacuum conveyor is large in volume and occupies a large area compared with the pneumatic vacuum feeder. The power source is provided separately by the external Roots vacuum pump or vortex vacuum pump.

3. Vacuum conveying equipment can reduce environmental and personnel pollution to materials, improve cleanliness.

4. The vacuum conveying equipment occupies a small space, can complete the powder conveying in a narrow space, so that the working space is beautiful and generous, not restricted by the length and distance.

5. The equipment reduces dust pollution, and the whole conveying process is carried out in a closed system, without powder leakage.

6. The equipment is easy to visual inspection, the equipment has no gap or dead Angle that is easy to make material accumulation, the surface is conducive to visual inspection.

Customizable Vacuum Conveyor Vertical Transport Powder Conveying Equipment

Application

Application scope:

1. Food industry additives, confectionery, afterbirth sugar pills, cocoa powder, crystals, etc.

2, Industrial raw materials, waste and other materials, agricultural bulk materials, etc.

3, Pharmaceutical industry powder materials, granular materials, mixed materials, tablets, capsules, etc.

4, Plastic industry: polystyrene particles, polyethylene particles, recycled rubber, polyurethane particles, vinyl - propylene particles, etc.
