The double cone mixer is a highly efficient and versatile mixing equipment widely used in the chemical, pharmaceutical, food and other industries. It adopts a unique design of two symmetrical conical containers and rotating mixing blades, which can quickly achieve continuous turning of materials and highly uniform mixing. This special structure is conducive to the full contact and dispersion of various powdered and granular materials, ensuring that even trace ingredients can be evenly distributed throughout the mixture.
Compared with traditional mixers, the double cone mixer is stable and reliable in operation, with low noise and vibration. It is equipped with functional modules such as temperature control and vacuum, and can also choose intelligent features such as automatic addition and unloading. With excellent mixing quality, flexible functional configuration and high production efficiency, the double cone mixer has become the preferred mixing and processing equipment for many chemical, pharmaceutical and other industries.
Model | W-300 | W-500 | W-1000 | W-1500 | W-2500 | W-4000 | W-6000 | W-8000 |
Production capacity (kg/time) | 150 | 250 | 500 | 750 | 1250 | 2000 | 3000 | 4000 |
Full volume (cubic meter) | 0.3 | 0.5 | 1 | 1.5 | 2.5 | 4 | 6 | 8 |
Mixing time (min) | 4-8 | 4-8 | 6-12 | 6-12 | 6-12 | 6-15 | 6-15 | 6-15 |
Motor power(KW) | 1.1 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 |
Cylinder speed (RPM) | 15 | 15 | 12 | 12 | 12 | 10 | 10 | 10 |
Dimension(L*W*H) | 1680*650*1600 | 2080*750*1900 | 2150*850*2100 | 2300*1600*3100 | 2500*1000*2450 | 2980*1580*2800 | 3500*1800*3000 | 3980*2000*3200 |
Weight (kg) | 310 | 550 | 800 | 950 | 1650 | 1880 | 2350 | 2680 |
*Support customization of various models of double cone mixers
The features of Double Cone Mixer:
1. Excellent mixing performance
The double cone mixer adopts a unique geometric structure design, which can continuously turn and stir the materials to achieve a high degree of mixing uniformity.
2. Flexible functional configuration
The double cone mixer can be equipped with temperature control, vacuum and other functional modules according to different application requirements. Some models also have intelligent features such as automatic addition and unloading. .
3. Closed design
The machine adopts a closed design, which is conducive to dust control and meets the hygiene and safety requirements of various industries.
4. High efficiency of production
Due to its excellent mixing performance and intelligent operation characteristics, the double cone mixer can greatly improve production efficiency, shorten mixing time, and improve overall production capacity.
(Contact us to customize different types of mixers)
1. Packaging:
To protect the equipment from damage during transportation, double cone mixers are usually packaged in sturdy and durable wooden boxes. Foam or other cushioning materials are filled inside to protect key parts such as the mixing shaft and motor.
The outer layer is then wrapped with moisture-proof and rain-proof plastic or canvas to prevent it from being affected by environmental factors.
2. Transportation:
Since double cone mixers are heavy equipment, cross-border transportation usually uses sea containers or large freight vehicles.
The transportation route and method will depend on the specific order situation and can be customized according to customer needs.
