Specifications
Brand Name :
PK
Model Number :
500/630/800/1000/1200 mm
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
500SETS/YEAR
Delivery Time :
ABOUT 30 DAYS
Packaging Details :
Standard export package
Model: :
BL type
Plate Width : :
500/630/800/1000/1200 mm
Max. Capacity :
450~1750 m³/h
Speed :
0.05~1.0 m/s
Chain Pitch :
200/250/320 mm
Motor brand can be domestic or imported :
Yutong, ABB, Siemens, WEG etc;
Gearbox brand can be domestic or imported :
Tailong, etc.
Max Inclination angle :
30°-35°
Description

Industrial Scraper Chain Conveyor BL Type Carbon Steel Large Throughput Mining

Introduction
Double chain conveyor scraper conveyor for mining chemicals has the advantages of simple structure, light weight, small volume, strong sealing and convenient installation and aintenance. It can transport, also can tilt or vertical transmission; not only can the single delivery, but also the combination of layout, tandem conveyor; can feeding, can also be the point of discharge, the conveyor process layout is more flexible. As the shell is closed, when conveying some easy-flying, toxic,explosive and high temperature materials, it has some prominent advantages.,such as improving the working conditions of the workers an preventing environmental pollution etc.


Industrial Scraper Chain Conveyor BL Type Carbon Steel Large Throughput Mining

Advantages and Features

  • Totally enclosed structure without pollution to the environment.
  • Light weight, small volume, space saving.
  • Convenient installation and maintenance.
  • Vertical or large inclined transportation, angles range from 30° to 90°.
  • Multiple material feeding point and discharging point.
  • Conveying distance is up to 40m.
  • Material temperature lower than 120°C.
  • Gear motor brand can be domestic or imported: Tailong, Siemens etc.


Industrial Scraper Chain Conveyor BL Type Carbon Steel Large Throughput Mining
Technical Parameter

MC type Scraper Conveyor
Type MC16 MC20 MC25 MC32 MC40
Trough Width (mm) 160 200 250 320 400
Bulk Density of Material (t/m³) 0.2~1.8
Conveying Length (m) 5~30

Conveying

Capacity

 Speed (m/s) 0.16 0.16 0.16 0.16 0.16
Capacity (m³/h) 11 15 23 36 55
Speed (m/s) 0.2 0.2 0.2 0.2 0.2
Capacity (m³/h) 14 19 29 46 70
Speed (m/s) 0.25 0.25 0.25 0.25 0.25
Capacity (m³/h) 17 23 36 58 90
Speed (m/s) 0.32 0.32 0.32 0.32 0.32
Capacity (m³/h) 22 30 46 74 110

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

♦ Material to be processed:
_

♦ Installation angle:
___° (if the installation is inclined)

♦ Bulk density:
t/m3

♦ lifting height:
___m (if there is slope angle)

♦ Water content:
%

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material temperature:
°C

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material is corrosive or not:
(Yes or No)

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Material is sticky or not:
(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Granule size of material:
mm

♦ Working environment:
(indoor or outdoor)

♦ Max. Granule size:
mm

♦ Working environment temperature:
°C

♦ Handling capacity:
t/h

♦ Working power supply:
3 Phase V Hz
♦ Conveying length (distance between inlet and outlet): m

♦ Quantity:
sets
♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
