50m Movable Green Carbon Steel Mobile Flat Belt Conveyor Fertilizer
50m Movable Green Carbon Steel Mobile Flat Belt Conveyor Fertilizer
50m Movable Green Carbon Steel Mobile Flat Belt Conveyor Fertilizer
50m Movable Green Carbon Steel Mobile Flat Belt Conveyor Fertilizer
Specifications
Brand Name :
PK
Model Number :
DY
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 SETS/YEAR
Delivery Time :
ABOUT 30 DAYS
Packaging Details :
Standard export package
Lifting Height :
0.8~12.5m
Capacity :
25~550m3/h
Gearbox brand can be domestic or imported :
Tailong, etc.
Slope Angle :
10° ~ 26°
Bearing :
LYC, HRB , WZS, FAG, NSK, SKF
Belt Width :
500/650/800/1000mm
Model :
DY
Description

50m Movable Green Carbon Steel Mobile Flat Belt Conveyor Fertilizer


Introduction

Portable belt conveyors is lightweight and portable, mobility applicable in bulk loading, transport packaging and other occasions, suit to diversified occasions, and easy maintenance. It can be widely used in chemical industry, coal, mine, electrical department, light industry, grain, transportation department etc. It is suitable for conveying various materials in granular or powder.

Advantages and Features

1. Light weight, one operator can move it easily.

2. Adopt chevron pattern conveyor belt to increase the maximum conveyor angle.

3. The conveyor length can be customized according to your requirement.

4. With wheels and can be moved to anywhere to save equipment number.

5. Easier for bags or bulk material stacking in warehouse to save your labor cost.

6.The Many kinds of material can be transported, also transport all kinds of bulk material , a variety of cartons, bags and other single-piece lightweight products, etc.

7. The noise is smaller than other kinds of conveyors , suitable for quiet work environment.

8. With wheels, the machine can be moved to the different working site.

Technical Parameter

Model

Belt

Width

(mm)

Length

(m)

Belt

Speed

(m/s)

Lifting

Height

(m)

Conveyor

Angle

(degree)

Capacity

(m3/h)
DY50 500 5-20 0.8-1.6 Adjustable 15-26 50-140
DY65 650 5-20 100-250
DY80 800 5-20 170-350
DY100 1000 5-20 270-550

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

For the bulk material

♦ Material to be processed:

♦Max. Granule size of material: mm

♦ Bulk Density: t/m3

♦ Handling capacity: t/h

♦ Material temperature: ºC;

♦ Conveyor length: m

♦ Water content: %

♦ The conveyor angle is adjustable or not: (Yes or No)

♦ Material is corrosive or not: (Yes or No)

♦ Max. Lifting height: m

♦ Material is sticky or not: (Yes or No)

♦ Working power supply: 3 Ph. V Hz
For the bagged / box material

♦ Weight of full-load bag / box:kg

♦ The conveyor angle is adjustable

or not: (Yes or No)

♦ Size of the full-load bag/box(L*W*H): mm

♦ Max. Lifting height: m
♦ Numbers of conveyed bags/boxes per hour:

♦ Working power supply: 3 Ph. V Hz

♦ Conveyor length: m

♦ Quantity: sets
