Large Angle Corrugated Conveyor Belt Heavy Duty Inclined Sidewall
Large Angle Corrugated Conveyor Belt Heavy Duty Inclined Sidewall
Large Angle Corrugated Conveyor Belt Heavy Duty Inclined Sidewall
Large Angle Corrugated Conveyor Belt Heavy Duty Inclined Sidewall
Specifications
Brand Name :
PK
Model Number :
DJB
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability :
1000SETS/YEAR
Delivery Time :
AOUT 30 DAYS
Packaging Details :
Standard export package
Belt Material :
Rubber
Working Type :
Continuous
Bearing Brand :
SKF,NSK,LYC
Motor Brand :
ABB,,Siemens
Belt Brand :
ContiTech,YOKOHAMA
Lifting Height :
5-80M
Description

Large Angle Corrugated Conveyor Belt Heavy Duty Inclined Sidewall

Introduction

This machine is a continuously conveying equipment for general purpose materials in bulk and adopted belt with waviness sides and diaphragm plate. It is specially using for big inclined angle conveying.It is widely used for coal, chemical industry, building materials, metallurgy, electric power, light industry grain, port, shipping etc. Specific gravity of bulk materials is 0.5-2.5 t/m³ It can be conveyed in the working environment where the temperature is during -15 degree to 140 degree.

Application

  • Coal and wood-chip fired power stations

  • Underground mining (coal and ore)

  • Shaft conveying for tunnelling and underground mining

  • Steel industry

  • Ship loading and unloading, ship to ship loading

  • Sand preparation in foundry plants

  • Silo feeding

  • Slope conveying in open pit mining

  • Waste recycling, soil purification and water treatment

  • Handling of large material flows in the horizontal path

Large Angle Corrugated Conveyor Belt Heavy Duty Inclined Sidewall

Technical Parameter

Belt Width

(mm)

Height of Sidewall

(mm)

Belt Speed

(m/s)

Angle of

Inclination

(°)

Capacity

(m³/h)
500 80 0.8-2.0 30-90 84
100 112
120 98
650 100 0.8-2.0 156
120 140
160 186
800 120 0.8-2.5 186
160 318
200 360
1000 160 1.0-2.5 428
200 483
240 683
1200 160 1.0-3.15 535
200 765
240 1077
300 1358
1400 200 1.0-3.15 920
240 1298
300 1657
400 2381
1600 200 1.25-3.15 1074
240 1515
300 1953
400 2807
1800 240 1.25-4.0 2200
300 2724
400 4106
500 5036

Capacity is under 30° angle and maximum belt speed.

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

♦ Material to be processed:

♦ Top horizontal section length:

m

♦ Bulk density:

t/m3

♦ Conveyor angle:

___°

♦ Water content:

%

♦ Lifting height:

___m

♦ Material temperature:

°C

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material is corrosive or not:

(Yes or No)

 ♦ Downstream equipment (what kind of equipment is used to feed the material):

♦ Material is sticky or not:

(Yes or No)

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Granule size of material:

mm

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Max. Granule size:

mm

♦ Working environment:

(indoor or outdoor)

♦ Handling capacity:

t/h

♦ Working environment temperature:

°C

♦ Conveying length:

m

♦ Working power supply:

3 Phase V Hz
♦ Bottom horizontal section length: m

♦ Quantity:

sets
