OEM Customized Cement Lime Fly Ash Chain Conveyor Removal System
OEM Customized Cement Lime Fly Ash Chain Conveyor Removal System
OEM Customized Cement Lime Fly Ash Chain Conveyor Removal System
OEM Customized Cement Lime Fly Ash Chain Conveyor Removal System
Specifications
Brand Name :
PK
Model Number :
MC160/200/250/320/400mm
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
600SETS/YEAR
Delivery Time :
ABOUT 30 DAYS
Packaging Details :
Standard export package
Model :
MC
Trough width :
160/200/250/320/400mm
Transport Speed :
0.16/0.20/0.25/0.32m/s
Capacity :
11~110m3/h
Allowed Material Density Range :
0.2~1.8t/m3
Inclined angle :
0~80°
Noise Level :
Less Than 80dB
Paint :
Polyurethane Paint
Description

OEM Customized Cement Lime Fly Ash Chain Conveyor Removal System

Introduction

OEM customized cement lime fly ash chain conveyor removal system is mainly composed of the first section, the middle section, the optional section, the tail section and the conveyor chain, the import and export materials, and the drive. The drive is divided into two types: left and right, and the drive type is selected according to the delivery volume and the delivery length. The feed inlet is divided into three types: the upper feed inlet, the lateral feed inlet, the two feed inlets, the discharge outlet is the head outlet, and the intermediate outlet and the middle outlet are also available for users to use.

OEM Customized Cement Lime Fly Ash Chain Conveyor Removal System

Advantages and Features

  • Totally enclosed structure without pollution to the environment.
  • Light weight, small volume, space saving.
  • Convenient installation and maintenance.
  • Vertical or large inclined transportation, angles range from 30° to 90°.
  • Multiple material feeding point and discharging point.
  • Conveying distance is up to 40m.
  • Material temperature lower than 120°C.
  • Gear motor brand can be domestic or imported: Tailong, , Siemens etc.

Technical Parameter

MC type Scraper Conveyor
Type MC16 MC20 MC25 MC32 MC40
Trough Width (mm) 160 200 250 320 400
Bulk Density of Material (t/m³) 0.2~1.8
Conveying Length (m) 5~30

Conveying

Capacity

 Speed (m/s) 0.16 0.16 0.16 0.16 0.16
Capacity (m³/h) 11 15 23 36 55
Speed (m/s) 0.2 0.2 0.2 0.2 0.2
Capacity (m³/h) 14 19 29 46 70
Speed (m/s) 0.25 0.25 0.25 0.25 0.25
Capacity (m³/h) 17 23 36 58 90
Speed (m/s) 0.32 0.32 0.32 0.32 0.32
Capacity (m³/h) 22 30 46 74 110

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

♦ Material to be processed:

_

♦ Installation angle:

___° (if the installation is inclined)

♦ Bulk density:

t/m3

♦ lifting height:

___m (if there is slope angle)

♦ Water content:

%

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material temperature:

°C

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material is corrosive or not:

(Yes or No)

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Material is sticky or not:

(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Granule size of material:

mm

♦ Working environment:

(indoor or outdoor)

♦ Max. Granule size:

mm

♦ Working environment temperature:

°C

♦ Handling capacity:

t/h

♦ Working power supply:

3 Phase V Hz
♦ Conveying length (distance between inlet and outlet): m

♦ Quantity:

sets
♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
