Perlite Drag Chain Conveyor Zinc Powder Gypsum Scraper Conveyor
Perlite Drag Chain Conveyor Zinc Powder Gypsum Scraper Conveyor
Perlite Drag Chain Conveyor Zinc Powder Gypsum Scraper Conveyor
Perlite Drag Chain Conveyor Zinc Powder Gypsum Scraper Conveyor
Specifications
Brand Name :
PK
Model Number :
MC160/200/250/320/400mm
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
600SETS/YEAR
Delivery Time :
ABOUT 30 DAYS
Packaging Details :
Standard export package
Model :
MC
Trough width :
160/200/250/320/400mm
Transport Speed :
0.16/0.20/0.25/0.32m/s
Capacity :
11~110m3/h
Inclined angle :
0~80°
Chain Type :
Roller Chain
Installation :
Technical Guidance
Warranty :
18 Months
Description

Perlite Drag Chain Conveyor Zinc Powder Gypsum Scraper Conveyor

Introduction

Perlite drag chain conveyor Zinc powder gypsum scraper conveyor is a new product for horizontal (or inclined 15%) conveying powdery, granular and small block materials.This product design is reasonable, the structure is novel, the service life is long, its service performance obviously surpasses the spiral conveyor, the buried scraper conveyor and other conveyor equipment, is one kind of ideal new conveyor equipment.The products are widely used in building materials, chemical industry, mining, metallurgy, electric power, grain and oil processing, machinery, transportation, port and transportation industries

FU type scraper conveyor is a conveying equipment which is traction components on the roller chain plate and continuous. This type of device with compact structure, good sealing, rational layout, application convenient maintenance, etc.

It is mainly used for grinding powder, particle, small lump with strong abrasive in horizontal or inclination, also widely used in chemical industry, metallurgy, mining, building materials, electric power, light industry, traffic, road construction, food processing industry, port, etc.

Perlite Drag Chain Conveyor Zinc Powder Gypsum Scraper Conveyor

Application:

Performance of chain scraper conveyor for transporting powder and small granular material is better than screw conveyor, scraper conveyor and other transport equipments. FU chain conveyor are widely used in building, chemical, thermal power, food processing, mining and other industries.

Technical Parameter

MC type Scraper Conveyor
Type MC16 MC20 MC25 MC32 MC40
Trough Width (mm) 160 200 250 320 400
Bulk Density of Material (t/m³) 0.2~1.8
Conveying Length (m) 5~30

Conveying

Capacity

 Speed (m/s) 0.16 0.16 0.16 0.16 0.16
Capacity (m³/h) 11 15 23 36 55
Speed (m/s) 0.2 0.2 0.2 0.2 0.2
Capacity (m³/h) 14 19 29 46 70
Speed (m/s) 0.25 0.25 0.25 0.25 0.25
Capacity (m³/h) 17 23 36 58 90
Speed (m/s) 0.32 0.32 0.32 0.32 0.32
Capacity (m³/h) 22 30 46 74 110

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

♦ Material to be processed:

_

♦ Installation angle:

___° (if the installation is inclined)

♦ Bulk density:

t/m3

♦ lifting height:

___m (if there is slope angle)

♦ Water content:

%

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material temperature:

°C

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material is corrosive or not:

(Yes or No)

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Material is sticky or not:

(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Granule size of material:

mm

♦ Working environment:

(indoor or outdoor)

♦ Max. Granule size:

mm

♦ Working environment temperature:

°C

♦ Handling capacity:

t/h

♦ Working power supply:

3 Phase V Hz
♦ Conveying length (distance between inlet and outlet): m

♦ Quantity:

sets
♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
