Mechanical Rock Ore Linear Vibrating Screen Mesh Easy Replacement
Mechanical Rock Ore Linear Vibrating Screen Mesh Easy Replacement
Mechanical Rock Ore Linear Vibrating Screen Mesh Easy Replacement
Mechanical Rock Ore Linear Vibrating Screen Mesh Easy Replacement
Specifications
Brand Name :
PK
Model Number :
ZS
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1000SETS/YEAR
Delivery Time :
AOUT 30 DAYS
Packaging Details :
Standard export package
Model :
ZS520/525/612/1020/1025/1030/1224
Capacity :
3~120m3/h
Layer :
1-5
Sieve Mesh :
2-325mesh
Power :
0.37*2~7.5*2(kw)
Mesh Material :
Stainless Steel
Equipment Angle :
0~10 Degree
Driven Force :
2 Vibrating Exciter
Description

Mechanical Rock Ore Linear Vibrating Screen Mesh Easy Replacement

Introduction
Mechanical rock ore vibration screen sieve with mesh easy replacement is a kind of new and efficient sieving equipment, which bears a linear track of its screen-box movement. This series is a successful model by the organic combination of probability theory with the engineering practice. The probability screen has an almost perfect performance because of its totally novel concept of design and its unique structure and screening fundamentals so that there lays an extensive prospect for its application.

Mechanical Rock Ore Linear Vibrating Screen Mesh Easy Replacement


Advantages and Feathers
1. Advanced structure, small volume, light weight, high efficiency, low noise, adopt new type of vibration motor as the direct drive, low investment cost
2. Screen has a simple structure, easy maintenance. Screen adopts high strength metal woven mesh, durable service, or uses polyurethane screen mesh.
3. It has seat type and hanging type for choice.

4.Open baffle at feeding position of the screen frame, increase the process capacity of raw material

5.Polyurethane screen as sieve surface, durable wear, corrosion resistance, long life

6.Hook belt fastening, sifting side plate reinforcement, strong and durable

7. Rubber soling shock absorption, low noise

8. Customize double layer screen, mesh hole size, stainless steel screen, galvanized screen for specific use


Technical datas:

Type Layer Sieve Dimension (mm) Sieve Mesh (mesh) Particle Size(mm) Capacity (t/h) Power (kW) Double Amplitude (mm) Frequency (r.p.m) Screen Angle (degree)
ZS-520 1-5 500X2000 2-325 <20mm <5 0.37x2 6-10 1460/960 0-10
ZS-525 1-5 500X2500 2-325 <20mm <8 0.37x2 6-10 1460/960 0-10
ZS-612 1-5 600X1200 2-325 <20mm <3 0.37x2 6-10 1460/960 0-10
ZS-1020 1-5 1000X2000 2-325 <20mm <12 0.75x2 6-10 1460/960 0-10
ZS-1025 1-5 1000X2500 2-325 <20mm <16 0.75x2 6-10 1460/960 0-10
ZS-1030 1-5 1000X3000 2-325 <20mm <20 1.1x2 6-10 1460/960 0-10
ZS-1224 1-5 1200X2400 2-325 <20mm <23 1.5x2 6-10 1460/960 0-10


Selection Conditions

♦ Material to be processed:

♦ Screen layer/deck/sieve number:

♦ Bulk density:

t/m3

♦ Mesh size of every screen layer/deck/sieve:

mm

♦ Material Temperature:

ºC

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Water Content:

%

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material is corrosive or not:

(Yes or No)

 ♦ Drive: (Domestic or International brand or designated brand?)

♦ Material is sticky or not:

(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Granule size of material:

mm

♦ Working environment:

(indoor or outdoor)

♦ Max. granule size:

mm

♦ Working environment temperature:

°C

♦ Particle distribution percentage:

♦ Working power supply:

3 Phase V Hz

♦ Handling capacity:

t/h

♦ Quantity:

sets
