Outdoor Stone Vibration Feeder Machine , Grizzly Vibrating Feeder
Outdoor Stone Vibration Feeder Machine , Grizzly Vibrating Feeder
Outdoor Stone Vibration Feeder Machine , Grizzly Vibrating Feeder
Outdoor Stone Vibration Feeder Machine , Grizzly Vibrating Feeder
Specifications
Brand Name :
PK
Model Number :
ZG25/30/60/80/100/200/300/400/500/750/1200/1800/2000
Certification :
CE Certificate,ISO9001:2015, BV, SGS,Business-license, ISO14000:2015
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1000SETS/YEAR
Delivery Time :
About 30 days
Packaging Details :
Standard export package
Capacity :
2-2000t/h
Type :
Seated
Model :
ZG25/30/60/80/100/200/300/400/500/750/1200/1800/2000
Power :
2*0.25,2*0.4,2*0.75,2*2.5,2*5.5kw
Double Amplitude :
2~8mm
Application :
Stone
Feeding Size :
＜420mm
Model of Vibrating Motor :
YZO-2.5-4,...YZO-75-6
Driving unit :
Vibration motor
Description

Outdoor Stone Vibration Feeder Machine , Grizzly Vibrating Feeder

Introduction
Outdoor Stone Grizzly Vibrating Feeder Vibration Feeding Equipment is Vibration Feeder is widely used in metallurgy, coal, mineral processing, building material, chemical industry and other industry using crushing and screening combined equipment. It is a linear vibrating equipment which is used for feeding kinds of materials such as block, granule, and powder uniformly and continuously. It can feed material for belt conveyor, vibrating conveyor, bucket elevator, vibrating screen, crusher etc.

Advantages and Features

1. Smooth vibration, reliable operation and longer service life;
2. The excitation force can be adjusted, the flow can be changed and controlled at any time, and the adjustment is convenient and stable;
3. The vibration motor is the excitation source, low noise, small power consumption, good adjustment performance, and no material charging phenomenon.

Outdoor Stone Vibration Feeder Machine , Grizzly Vibrating Feeder
Technical data:

Model Feeding Size
(mm)		 Processing Capacity
(t/h)		 Model of Vibrating Motor Power
(kW)		 RPM
(r/min)		 Double Amplitude
(mm)		 Vibrating Force
(N)
ZG-25 60 25 YZO-2.5-4 0.25x2 1500 2-3 5000
ZG-30 60 30 YZO-2.5-4 0.25x2 1500 2-3 5000
ZG-60 90 60 YZO-5-4 0.4x2 1500 2-4 10000
ZG-80 160 80 YZO-5-4 0.4x2 1500 2-4 10000
ZG-100 210 100 YZO-8-4 0.75x2 1500 2-5 16000
ZG-200 270 200 YZO-8-4 0.75x2 1500 2-5 16000
ZG-300 300 300 YZO-17-4 0.75x2 1500 2-5 34000
ZG-400 300 400 YZO-17-4 0.75x2 1500 3-5 34000
ZG-500 300 500 YZO-17-4 0.75x2 1500 3-5 34000
ZG-750 400 750 YZO-30-6 2.5x2 1000 4-6 60000
ZG-1200 400 1200 YZO-30-6 2.5x2 1000 4-6 60000
ZG-1800 420 1800 YZO-75-6 5.5x2 1000 5-8 150000
ZG-2000 420 2000 YZO-75-6 5.5x2 1000 5-8 150000


Selection Conditions

♦ Material to be processed:

♦ Installation forms:

___(Hanging-type or seat-type)

♦ Bulk density:

t/m3

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material Temperature:

ºC

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Water Content:

%

 ♦ Motor: (Domestic or International brand or designated brand?)

♦ Material is corrosive or not:

(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Material is sticky or not:

(Yes or No)

♦ Working environment:

(indoor or outdoor)

♦ Granule size of material:

mm

♦ Working environment temperature:

°C

♦ Max. granule size:

mm

♦ Working power supply:

3 Phase V Hz

♦ Handling capacity:

t/h

♦ Quantity:

sets
