Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement
Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement
Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement
Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement
Specifications
Brand Name :
PK
Model Number :
TH
Certification :
CE Certificate, ISO9001:2015, ISO14001:2015, BV, SGS, Business-license
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1000SETS/YEAR
Delivery Time :
about 35 days
Packaging Details :
Standard export package
Power(w) :
As the model you choose
Traction Component :
High strength ring chain
Condition :
New
Capacity :
15~ 613m3/h
Max. Lifting height :
52m
Bucket Volume :
1.9L~ 92L
Pitch of Buckets :
500~ 864mm
Material :
Stainless Steel, Carbon steel
Description

Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement

Introduction

Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement also named double chain bucket elevator. Ring chain type uses forging ring chain as the traction component, compared with TD type belt bucket conveyor. Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement is widely used for bulk material which density less than 1.5t/m3, such as coal, cement, sand, fertilizer, food, etc.

Advantages and Features

  • Excellent sealing, less environmental pollution.
  • The bucket elevator wheels have bolted rims easily replaceable fabricated in wear resistant steel.
  • Symmetrical weight distribution to long life of chain and driveshaft.
  • Energy conservation and less maintenance ensure the machine a very low cost.
  • Advanced design principle has ensured the reliability of machine operation.
  • High manufacture accuracy. The housing case is of good rigidity and beautiful appearance by the edge folding and intermediate beading.
  • Lifting height up to 60m.
  • Compact installation arrangement.
  • Height can be customized according to your need.

Th Mining Safety Handling Galvanized Silo Bucket Elevator For Bulk Cement

Technical Parameter

TH type Ring Chain Bucket Elevator
Model TH160 TH200 TH250 TH315 TH400 TH500 TH630 TH800 TH1000 TH1250
Bucket Type Zh Sh Zh Sh Zh Sh Zh Sh Zh Sh Zh Sh Zh Sh Zh Sh Zh Sh Zh Sh

Capacity

(m³/h)

 15 25 18 29 31 48 35 60 60 94 75 118 114 185 146 235 125 365 396 613

Bucket Width

(mm)

 160 200 250 315 400 500 630 800 1000 1250

Bucket Volume

(L)

 1.2 1.9 1.5 2.5 3.0 4.6 3.75 6.0 5.9 9.5 9.3 15.0 14.6 23.6 23.3 37.5 37.5 58.3 59.4 92

Bucket Spacing

(mm)

 500 512 688 920 864

Chain

Diameter X Pitch

(mm)

 14X50 18X64 22X86 26X92 30X108
Ring Number 9 7 7 9 7
Chain Quantity 2 2 2 2 2

Single chain

broken load

(kN)

 ≥190 ≥320 ≥480 ≥570 ≥890

Bucket Speed

(m/s)

 1.2 1.4 1.5 1.6

Main sprocket

diameter

(mm)

 300 365 520 630 710 800 900 1000 1250 1250

Speed of

main shaft

(r/min)

 69.71 63.22 44.11 42.5 37.6 35.8 31.8 30.5 24.4 24.4

Max. Material

particle size

(mm)

 20 25 30 35 40 50 60 65 70 75

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

♦ Material to be processed:

_

 ♦ Lifting height (distance between inlet and outlet): m

♦ Bulk density:

t/m3

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Water content:

%

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material temperature:

°C

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Material is corrosive or not:

(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Material is sticky or not:

(Yes or No)

♦ Working environment:

(indoor or outdoor)

♦ Granule size of material:

mm

♦ Working environment temperature:

°C

♦ Max. Granule size:

mm

♦ Working power supply:

3 Phase V Hz

♦ Handling capacity:

t/h

♦ Quantity:

sets
