Vertical Sidewall Conveyor Belt Lifting Machine Industrial Dust Collecting Line
Vertical Sidewall Conveyor Belt Lifting Machine Industrial Dust Collecting Line
Vertical Sidewall Conveyor Belt Lifting Machine Industrial Dust Collecting Line
Vertical Sidewall Conveyor Belt Lifting Machine Industrial Dust Collecting Line
Specifications
Brand Name :
PK
Model Number :
DJB
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability :
1000SETS/YEAR
Delivery Time :
AOUT 30 DAYS
Packaging Details :
Standard export package
Model :
DJB
Angle :
90 Degrees
Baffle Height :
75mm~260mm
Baffle Shapes :
C/T/Tc/Tcs
Side Wall Height :
100/120/160/200/240/300mm
Particle Range :
50mm~450mm
Description

Vertical Sidewall Conveyor Belt Lifting Machine Industrial Dust Collecting Line

Introduction

This machine is a continuously conveying equipment for loose bulk material such as coal, sand, stone, grain, etc and some powdered material, so its slope of application is very wide, including mine, cement plant, chemical industry, metallurgy and agriculture, electric power, light industry, grain, port, shipping ect, when the mateial need to be conveyor at a big inclined angle, the steeply inclinded belt conveyor also could conveying material vertically.

Advantages and Features

1.Flexible transportation – can convey all kinds of bulk materials such as coal, ore, sand, fertilizer and grain in horizontal, oblique, vertical or other angle directions.

2.High tensile strength

3.Increases belt capacity

4.No spillage with steep angle conveying

5.Decrease necessary conveyor footprint

6.No transfer points- the belt are capable of turning at any angle right from feed hopper to discharge point

7.Maximum utilization of space – able to convey material at angles up to 90 degree

Vertical Sidewall Conveyor Belt Lifting Machine Industrial Dust Collecting Line

Technical Parameter

Belt Width

(mm)

Height of Sidewall

(mm)

Belt Speed

(m/s)

Angle of

Inclination

(°)

Capacity

(m³/h)
500 80 0.8-2.0 30-90 84
100 112
120 98
650 100 0.8-2.0 156
120 140
160 186
800 120 0.8-2.5 186
160 318
200 360
1000 160 1.0-2.5 428
200 483
240 683
1200 160 1.0-3.15 535
200 765
240 1077
300 1358
1400 200 1.0-3.15 920
240 1298
300 1657
400 2381
1600 200 1.25-3.15 1074
240 1515
300 1953
400 2807
1800 240 1.25-4.0 2200
300 2724
400 4106
500 5036

Capacity is under 30° angle and maximum belt speed.

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.

Selection Conditions

♦ Material to be processed:

♦ Top horizontal section length:

m

♦ Bulk density:

t/m3

♦ Conveyor angle:

___°

♦ Water content:

%

♦ Lifting height:

___m

♦ Material temperature:

°C

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material is corrosive or not:

(Yes or No)

 ♦ Downstream equipment (what kind of equipment is used to feed the material):

♦ Material is sticky or not:

(Yes or No)

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Granule size of material:

mm

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Max. Granule size:

mm

♦ Working environment:

(indoor or outdoor)

♦ Handling capacity:

t/h

♦ Working environment temperature:

°C

♦ Conveying length:

m

♦ Working power supply:

3 Phase V Hz
♦ Bottom horizontal section length: m

♦ Quantity:

sets
