Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part
Specifications
Brand Name :
PK
Certification :
CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
Place of Origin :
Xinxiang City, Henan Province,China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
10000SETS/YEAR
Delivery Time :
ABOUT 10 DAYS
Packaging Details :
Standard export package
Screw Diameter :
150/200/250/300/400/500/600mm
Screw pitch :
150/200/250/300/400/500mm
Rotating Speed :
20/25/32/40/50/63rpm
Capacity :
14~110 m3/h
Max.Conveying Distance :
55m
Power :
1.1KW~22kw
Reducer :
YZQ250/350/400/500/650/750/850
Motor brand can be domestic or imported :
Yutong, ABB, Siemens, WEG etc;
Description

Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part

Introduction

The screw conveyor is a kind of machine that uses the motor to drive the screw to turn and push the material to realize the purpose of conveying. It can be transported horizontally, obliquely or vertically. It has the advantages of simple structure, small cross-sectional area, good sealing, easy operation, easy maintenance and easy closed transportation.

Features:

1. The large bearing capacity, safe and reliable.

2. Strong adaptability, easy installation and maintenance, long service life.

3. The machine is small in size, high speed, ensure rapid delivery uniformity.

4. The discharge end is equipped with cleaning device, low noise, strong adaptability, in and out of the mouth position arranged flexibly.

5. Good sealing, shell made of seamless steel tube end use flange connection each other as a body, good rigidity.

Screw Blade Universal Joint Hanging Bearing Screw Conveyor Spare Part

Technical Parameter:

LS screw conveyor specification & technical parameters
Type LS160 LS200 LS250 LS315 LS400 LS500 LS630 LS800 LS1000 LS1250
Diameter/mm 160 200 250 315 400 500 630 800 1000 1250
Screw pitch/mm 160 200 250 315 355 400 450 500 560 630
technical parameters n 112 100 90 80 71 63 50 40 32 25
Q 8 14 24 34 64 100 145 208 300 388
n 90 80 71 63 56 50 40 32 25 20
Q 7 12 20 26 52 80 116 165 230 320
n 71 63 56 50 45 40 32 25 20 16
Q 6 10 16 21 41 64 94 130 180 260
n 50 50 45 40 36 32 25 20 16 13
Q 4 7 13 16 34 52 80 110 150 200
n---Rotation Speed (r/min), Allowable Deviation < 10% Q---Capacity (m3/h), Filling Factor = 0.33


Selection Conditions

♦ Material to be processed:

_

♦ Installation angle:

___° (if the installation is inclined)

♦ Bulk density:

t/m3

♦ lifting height:

___m (if there is slope angle)

♦ Water content:

%

 ♦ Upstream equipment (what kind of equipment is used to feed the material):

♦ Material temperature:

°C

 ♦ Downstream equipment (what kind of equipment is used to discharge the material):

♦ Material is corrosive or not:

(Yes or No)

 ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

♦ Material is sticky or not:

(Yes or No)

 ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

♦ Granule size of material:

mm

♦ Working environment:

(indoor or outdoor)

♦ Max. Granule size:

mm

♦ Working environment temperature:

°C

♦ Handling capacity:

t/h

♦ Working power supply:

3 Phase V Hz
♦ Conveying length (distance between inlet and outlet): m

♦ Quantity:

sets
♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
