Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller
Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller
Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller
Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller
Specifications
Brand Name :
PK
Model Number :
Φ76/Φ89/Φ108/Φ133/Φ159/Φ194
Certification :
CE Certificate, ISO9001:2015, ISO14001:2015, BV, SGS, Business-license
Place of Origin :
Xinxiang City, Henan Province, China
MOQ :
5
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
30000 Pieces/Year
Delivery Time :
20 Days
Packaging Details :
Standard Wooden Package
Product name :
Conveyor Roller
Material :
Carbon Steel/Stainless Steel or As Requested
Size :
As per customer's request
Length :
Customised
Shaft :
45#steel (GB) equal to C45 (DIN)
Bearing :
As per customer's request
Color :
Customers' Requirements
Advantage :
Conveyor roller factory direct
Standard :
DIN, CEMA, ISO, GB, SGS
Installation :
Engineer Guide, Turning
Usage :
Transportation, Conveyor, Material Transimission
Description

Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller

Introduction

Products range of conveyor belt roller includes: carrying roller, flat return roller, impact roller, vertical roller, self-alignment roller, side roller, rubber disc roller, roller frame, roller set. pulley etc. Size: D76-219mm L190-3500mm and could be customised; We can also manufacture as per standard: CEMA/JIS/DIN/Australia, etc.

Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller
Features

1. Adopt cold-drawn round steel with higher surface precision as the shaft material.
2. Good coaxiality and cylindricity.
3. Adopt special technology, can reduce the innerstress and welding heat deformation produced during assembling substantially.
4. Rotate resistance is small, weight is stable, service life can be more than 50000 hours
5. Non-contact type labyrinth seals, higher dust-proof and water-proof properties.
6. Roller with good dynamic and static balance performance.
7. Easy to maintain and replace.
8. Smooth surface, prevent damaging of conveyor belt.

Production Technology and Process

Heat Resistant Conveyor Belt Roller , Low Radial Runout Steel Idler Roller

Technical Parameter (Parts)

Diameter

(mm)

Length

(mm)

Pipe Thickness

(mm)

Shaft Diameter

(mm)

 Bearing Model Seal Type
63.5 200 3 15 6203/4C Labyrinth
600 3 15 6203/4C Labyrinth
76 200 3 20 6204/4C Labyrinth
250 3 20 6204/4C Labyrinth
600 3 20 6204/4C Labyrinth
750 3 20 6204/4C Labyrinth
89 200 3.5 20 6204/C4 Labyrinth
250 3.5 20 6204/C4 Labyrinth
315 3.5 20 6204/C4 Labyrinth
600 3.5 20 6204/C4 Labyrinth
750 3.5 20 6204/C4 Labyrinth
950 3.5 20 6204/C4 Labyrinth
108 250 3.5 25 6205/C4 Labyrinth
315 3.5 25 6205/C4 Labyrinth
380 3.5 25 6205/C4 Labyrinth
465 3.5 25 6205/C4 Labyrinth
530 3.5 25 6205/C4 Labyrinth
600 3.5 25 6205/C4 Labyrinth
750 3.5 25 6205/C4 Labyrinth
950 3.5 25 6205/C4 Labyrinth
1150 3.5 25 6205/C4 Labyrinth
1400 3.5 25 6205/C4 Labyrinth
1600 3.5 25 6205/C4 Labyrinth
133 250 4 25 6305/C4 Labyrinth
315 4 25 6305/C4 Labyrinth
380 4 25 6305/C4 Labyrinth
465 4 25 6305/C4 Labyrinth
530 4 25 6305/C4 Labyrinth
600 4 25 6305/C4 Labyrinth
700 4 25 6305/C4 Labyrinth
800 4 25 6305/C4 Labyrinth
950 4 25 6305/C4 Labyrinth
1150 4 25 6305/C4 Labyrinth
1400 4 25 6305/C4 Labyrinth
1600 4 25 6305/C4 Labyrinth
159 315 4.5 30 6306/C4 Labyrinth
380 4.5 30 6306/C4 Labyrinth
465 4.5 30 6306/C4 Labyrinth
530 4.5 30 6306/C4 Labyrinth
600 4.5 30 6306/C4 Labyrinth
700 4.5 30 6306/C4 Labyrinth
800 4.5 30 6306/C4 Labyrinth
1150 4.5 30 6306/C4 Labyrinth
1400 4.5 30 6306/C4 Labyrinth
1600 4.5 30 6306/C4 Labyrinth
Note: All the parameters are for reference only, we can design and manufacture as per your requirements.
