600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder
600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder
600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder
600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder
Specifications
Brand Name :
AAREAL
Model Number :
AM
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
5 sets per month
Delivery Time :
20~35 work days after order confirmed
Packaging Details :
Fumigation-free plywood wooden case for export
Other Names :
tumbler screen, tumbler screener, tumbler screening machine, tumbling screen
Movement :
three-dimensional motion
Feeding Rate :
1kg/h – 50 ton/h
Speed Rang :
180-280 min-1
Screening Precision :
up to 90% ~ 99.9%
Layers of Screen :
1~5 layers of screen
Mesh Cleaning Method :
self-cleaning ball system, ultrasonic system, rolling brush, air brush etc.
Machine Diameter :
600mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm etc.
Optional Device :
quick clamps, pneumatic lifting devices etc.
Application :
spherical mineral granules, nickel ore, food additives, food flour, micronised materials, mineral powders, plastic powders, plastic powder, glass beads, xylitol, citric acid, calcium carbonate etc.
Description

600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder

Overview of 600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder:

600-2300mm ultrasonic tumbler screening machine for aluminium are used for bulk material grading, safety screening, and dedusting in all industrial sectors. They are particularly well-suited to the fine and extremely fine screening of dry bulk materials and precise grading with up to 7 particle sizes.

A gentle screening machine ideally suited to separate and de-dust dry, powdered and granular products. Particularly suitable for high feed rates and multi-deck separations of fine, lightweight and difficult to screen products.

Application of 600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder​​:

1. Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice etc.

2. Chemical industry: resin pigment, medicine, grease, paint, palette etc.

3. Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry etc.
4. Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide etc.
5. Mechanical industry: casting sand, powder metallurgy, electromagnetic material andmetal powder etc.

Important Information About 600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder You May Care:

Motion involute spiral motion, three-dimensional
Speed Rang 180-280 min-1
Screening Accuracy upto 90%~99.9%
Mesh Cleaning Method bouncing ball cleaning, ultrasonic cleaning, brush cleaning, air cleaning, ultrasonic air cleaning, air brush cleaning
Screen Structure whole adhesive screen, or splicing segmented screen etc.
Layers of Screen 1~5 layers of screen
Diameter 600mm, 1000mm, 1200mm, 1400mm, 1500mm, 1600mm, 1800mm, 2000mm, 2100mm, 2300mm, 2600mm etc.
Advantages soft rock screening will not destroy the particles original structure of the material and not easy to produce static electricity
Optional quick clamps, pneumatic lifting devices etc.
Application can be used for material that is flammable, explosive and easy to generate static

600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder

Pneumatic Lifting Device BALANCE IS IMPORTANT !!

Working Principle of 600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder​​​:

AAREAL tumbler screening machine is an artificial imitation of shaking low frequency vibration sieve, working principle is synthesis of transient motion displacement and this displacement in the radial direction of the axis of circular motion (helical motion), can adjust the eccentricity nonlinear three-dimensional motion of the exciter, the material also produces same motion approximation manual jobs, so as to achieve the purpose of screening, combined with sieving attachment can get more ideal screening effect. Suitable for circular, cylindrical, sheet, and even regular shapes easy to block network and require sophisticated screening materials.

600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder

600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder

Anti-blinding System:

– Rubber balls
– Rotating plastic roller brush arms
– Rotating air-jet nozzle arms
– Ultrasound converters
– Combinations

Technical Parameters of 600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder​​​:

600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder

Model Screen Area (m²) Layers of Screen Motor Power (KW)
AM-600 0.28 1~5 0.25
AM-1000 0.72 1~5 1.5
AM-1200 1.10 1~5 1.5
AM-1500 1.80 1~5 2.2
AM-1800 2.30 1~5 4.0
AM-2000 2.60 1~5 4.0
AM-2300 3.90 1~5 4.0
AM-2600 5.30 1~5 5.5
AM-2900 6.40 1~5 5.5

Features of 600-2300mm Ultrasonic Tumbler Screening Machine For Aluminium Oxide Powder​​​:

1. Multiple Screens can be added to get an array of grades.
2. Extreme High Efficiency even with products having lower bulk densities.
3. Quick clamping arrangement to minimize the change over time.

4. Low Noise creation.
5. Optional Anti Chocking Systems such as Ball Tray, Soft Ware Resistant PU Pipe Tray & Ultrasonic System.
6. Screens are replaceable with our existing Vibro Screens.
7. Equipped with Heavy Machine Base for better stability.
