100MV Digital Signal Generator Analog Transmitter Source Simulator
100MV Digital Signal Generator Analog Transmitter Source Simulator
100MV Digital Signal Generator Analog Transmitter Source Simulator
100MV Digital Signal Generator Analog Transmitter Source Simulator
Specifications
Brand Name :
VICTOR
Model Number :
VICTOR 71A
Certification :
CE
Place of Origin :
CHINA
MOQ :
1pcs
Price :
USD55/pc
Payment Terms :
T/T, Western Union, L/C, Paypal
Supply Ability :
1000pcs available
Delivery Time :
5 to 30 days
Packaging Details :
12pcs/Carton; Carton Size: 430mm*350mm*22.50mm
Color :
Blue and Black
Size :
205 × 95 × 42 mm
Product Name :
Signal Generator
Model No. :
VICTOR 71A
Packing Details :
12pcs/Carton; Carton Size: 430mm*350mm*22.50mm
Accuracy :
0.2% accuracy
Weight :
Approx. 500 g (including batteries)
Power supply :
one 9 V alkaline battery (6LR61)
Description

100MV Digital Signal Generator Analog Transmitter Source Simulator

VICTOR 71A l Signal Generator Current and voltage process calibrator Analog Transmitter Source Simulator

Description

This series of meters are categorized into the standard and thermocouple type. This manual is illustrated based on the thermocouple type.

This series of meters has the following functions:

  • 100 mV, 30 V DC voltage measurement, 20 mA DC current measurement, and switching value measurement;
  • 100 mV, 30 V DC voltage output, 20 mA DC current output and SIMULATE output;
  • V, mA manual step output,automatic waveform output;
  • Simultaneous display of V, mA and percentage;
  • Loop detection function: It simultaneously provides the 24 V loop power supply and measures the current.

The following functions are added to the thermocouple type:

  • Eight scale division (i.e., R, S, B, K, E, J, T and N) thermocouple measurement and output function;
  • Temperature display in Celsius degree and Fahrenheit degree;
  • Automatic and manual cold junction compensation function.

Open-package Inspection

Check the goods to see if they are damaged during delivery. Check if the goods are complete, and keep the packing materials for future delivery.

This meter comes with the following standard accessories:

• One pair of test leads (with alligator clips)

• One manual

• One 9 V alkaline battery (6LR61)

Technical Specification

General Characteristics

Display refresh 2~3 times/second
Overload protection 50mA/30V
Working temperature and humidity range 0~40 ºC and a relative humidity below 85% (no condensation)
Storage temperature and humidity range -20 ºC～60 ºC and a relative humidity below 90% (no condensation)
Precision ensures the temperature and humidity range 23±5ºC and a relative humidity below 75% (no condensation)
Temperature coefficient 0.1 × basic precision/℃ (temperature range <18 ℃ or >28 ℃)
Ambient conditions for use Indoor and outdoor use (not waterproof), with an elevation of 0~2000 m
Outrange display OL
Battery kind 9V (6LR61) alkaline battery one
Power consumption

When alkaline battery is used

Loop current measurement and DC current output (SOURCE) 20mA (a load of 1000Ω): approx. 1000mVA

Other work function: approx. 300mVA
Low battery Display battery sign
Automatic shutdown No operation for about 15 min by default
Preheating time 10 min
Close the meter enclosure for calibration No need for internal adjustment
Size 147(L)×75(W)×42(D)mm
Weight Approx. 230 g
Calibration cycle One year

Detailed Precision Index of Measurement

Measurement Function Range Measure Range Resolution Accuracy Notes
DC voltage 100mV -10.0mV～110.0mV 100uV 0.2%+4

• Input impedance: 30V: 300kΩ (nominal value)

mV:>1MΩ (nominal value)

• Common mode rejection: 50Hz or 60Hz >80dB

• Series mode rejection: 50Hz or 60Hz > 40dB

• Overvoltage protection:30V (peak to peak value)
30V -5.00V～30.00V 10mV 0.2%+4
DC current 20mA 0.00mA～22.00mA 0.01mA 0.2%+4

• Overload protection: 50mA/30V

• Load voltage: approx. 18mV/mA
Thermocouple R 0°C～1760°C 1°C 0.2%+4 • Thermocouple measurement adopts ITS-90 thermometric scale,whose precision does not include error of the cold junction compensation, and the impact of thermoelectrical potential
S 0°C～1760°C
B 400°C～1820 °C
K -200°C～1370°C
E -200°C～1000°C
J -200°C～1200°C
T -200°C～400°C
N -200°C～1300 °C

Detailed Precision Index of Output

Output Function Range Output Setting Range Resolution Accuracy Notes
DC voltage 100mV 0.0mV～110.0mV 100uV 0.2%+4 • Maximum output current 1mA
10V 0.00V～11.00V 10mV 0.2%+4 • Maximum output current 5 mA (<10V)
DC current 20mA 0.00～22.00mA 0.01mA 0.2%+4 • 20mA maximum load: 1KΩ

Analog transmitter

SIMULATE

 -20mA 0.00～-22.00mA 0.001mA

• External power supply: 5～28V

• 20mA maximum load: 1KΩ
Loop power supply LOOP 24V ±10% • Maximum output current 25mA
Thermocouple R 0°C～1760°C 1°C 0.2%+4 • Thermocouple measurement adopts ITS-90 thermometric scale,whose precision does not include error of the cold junction compensation, and the impact of thermoelectrical potential
S 0°C～1760 °C
B 400°C～1800°C
K 0°C～1350°C
E 0°C～700°C
J 0°C～950°C
T 0°C～400°C
N 0°C～1300°C
Capacitive load≥0.01uF

Technical Data

Project VICTOR 71A VICTOR 71B
SOURCE DC millivolt Range 0～110mV 0～110mV
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 100uV 100uV
DC voltage Range 0 ～ 10V 0 ～ 10V
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 10mV 10mV
DC current Range 0~22mA 0~22mA
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 0.01mA 0.01mA
Sink current Range 0~22mA 0~22mA
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 0.01mA 0.01mA
External power supply 5 ～ 28V 5 ～ 28V
Thermocouple Range 8 types(R/S/K/E/J/T/B/N)
Basic accuracy 0.2%+4dgt
Resolution 1℃
MEASURE DC millivolt Range -10~110mV -10~110mV
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 100uV 100uV
DC voltage Range -5~30V -5~30V
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 10mV 10mV
DC current Range 0~22mA 0~22mA
Basic accuracy 0.2%+4dgt 0.2%+4dgt
Resolution 0.01mA 0.01mA
Loop power Range 24V 24V
Basic accuracy 10% 10%
Limit current 25mA 25mA
Thermocouple Range 8types(R/S/K/E/J/T/B/N)
Basic accuracy 0.2%+4dgt
Resolution 1℃
Other functions Manual Step Output √ √
Automatic Waveform Output √ √
Standard Quantity Per Carton 12pcs 12pcs
Standard Carton Measurement 430mm*350mm*22.50mm 430mm*350mm*22.50mm
Standard Carton Cross Weight 7Kg 7Kg
