Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Specifications
Brand Name :
Victory
Model Number :
Cr20Ni80
Certification :
CE
Place of Origin :
China
MOQ :
5
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 tons per month
Delivery Time :
7-20 days
Packaging Details :
Spool package with Carton box, Coil package with polybag for Resistance wire
Material :
Nickel, Chromium
Nickel(Min) :
77%
Resistivity :
1.09+/-0.05
Tensile Strength :
637MPA
Elongtation :
≥20%
Application :
Heating, Resistivity
Condition :
Hard / Soft
Sureface :
Bright, Oxided, Acide
Name :
Resistance wire
Description

Nickel Chrome Resistance Alloy Wire Cr20Ni80,NiCr 8020 Nichrome Wire

NiCr Series

Nichrome wire, specifically the Cr20Ni80 alloy, is highly valued for its unique properties. When heated, it exhibits a minimum electrical resistance, making it ideal for use in electrothermal equipment. Additionally, it possesses elevated temperature strength and high ductility, allowing for various forms of machining such as chiseling, welding, stamping, and drawing. The alloy also holds its shape well, adding to its durability and reliability.

Despite its high price, the performance of Nichrome wire justifies the cost. The Cr20Ni80 and Cr15Ni60 alloys are the most popular brands due to their exceptional properties. H20N80 comprises 20% chromium and 80% nickel, resulting in a resistivity of 650 Ohms/cmf and a melting temperature of 1200°C.

Overall, Nichrome wire is a versatile and reliable material that is widely used in the electrical industry. Its unique properties make it an excellent choice for heating applications and other forms of electrothermal equipment. Despite its cost, the durability and reliability of this alloy make it a worthwhile investment.

Size dimension range:

Wire: 0.01-10mm

Ribbons: 0.05*0.2-2.0*6.0mm

Strip: 0.05*5.0-5.0*250mm

NiCr series: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30

Performance material Cr10Ni90 Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
Composición Ni 90 Rest Rest 55.0～61.0 34.0～37.0 30.0～34.0
Cr 10 20.0～23.0 28.0～31.0 15.0～18.0 18.0～21.0 18.0～21.0
Fe － ≤1.0 ≤1.0 Rest Rest Rest
Temperatura máxima℃ 1300 1200 1250 1150 1100 1100
Punto de fusion ℃ 1400 1400 1380 1390 1390 1390
Densidad g/cm3 8.7 8.4 8.1 8.2 7.9 7.9
Resistividad μΩ·m,20℃ 0.76±0.05 1.09±0.05 1.18±0.05 1.12±0.05 1.00±0.05 1.04±0.05
Alargamiento a la ruptura ≥20 ≥20 ≥20 ≥20 ≥20 ≥20
Calor especifico J/g.℃ － 0.44 0.461 0.494 0.5 0.5
Conductividad térmica KJ/m.h℃ － 60.3 45.2 45.2 43.8 43.8
Coeficiente de expansión de líneas a×10-6/(20～1000℃) － 18 17 17 19 19
Estructura micrográfica － Austenite Austenite Austenite Austenite Austenite
Propiedades magnéticas － Nonmagnetic Nonmagnetic Nonmagnetic Weak magnetic Weak magnetic

Form Specification
Wire Diameter=0.025mm~8mm
Flat wire Width=0.40~6.0mm Thick=0.03~0.50mm
Strip width=8~250mm Thick=0.05~3.0mm
Bar Diameter=8~100mm Long=50~1000

Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
Shape
Size(mm)
Wire
0.05-7.5
Rod
8-50
Ribbon
(0.05-0.35)*(0.5-6.0)
Strip
(0.5-2.5)*(5-40)

Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire Lowest Price Nichrome Alloy Cr20Ni80 Ni80 Wire Cr15Ni60 Electric Resistance Wire
