Specifications
Brand Name :
Victory
Model Number :
Inconel 600
Certification :
ISO9001
Place of Origin :
China
MOQ :
5 Kg
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 tons per month
Delivery Time :
7-20 Days
Packaging Details :
Inconel 600 rod packed in Spool Carton box, Coil package with polybag,then in woodencase
Name :
Inconel 600 bar
Material :
Nickel Chromium Iron
Ni (Min) :
72%
Density :
8.47 g/cm3
Melting point :
1,370-1,410°C
Elongation (≥ %) :
30 %
Thermal conductivity :
15.9 W/m·K
Sureface :
Bright,Oxided
Application :
Construction, IndustryOil drilling tools, piping systems, storage tanks and reactors
Yield strength :
240 MPa
Tensile strength :
550 MPa
Hardness :
≤ 160 HB
Description

Introduction:


Inconel 600 Bar, a nickel-chromium-iron alloy, possesses remarkable properties that make it a valuable material in various industries, including the oil and gas sector. With a minimum nickel content of 72% and a density of 8.47 g/cm3, it exhibits excellent corrosion resistance and high-temperature stability. The melting point of Inconel 600 Bar ranges from 1,370 to 1,410°C.

In terms of mechanical properties, it offers a yield strength of 240 MPa, a tensile strength of 550 MPa, and an elongation of at least 30%. The hardness, measured in terms of Brinell hardness, is ≤ 160 HB. Furthermore, it has a thermal conductivity of 15.9 W/m·K, facilitating efficient heat transfer.

Inconel 600 Bar finds significant application in the oil and gas industry, particularly in the construction and drilling sectors. It is extensively used in the manufacturing of oil drilling tools, such as drill bits, for its corrosion resistance and mechanical strength, ensuring reliable performance in demanding drilling environments. Additionally, it is employed in piping systems, storage tanks, and reactors, where its corrosion resistance is crucial for withstanding corrosive fluids and harsh operating conditions.

In summary, Inconel 600 Bar, with its excellent corrosion resistance, high-temperature stability, and mechanical properties, plays a vital role in the oil and gas industry. Its applications encompass oil drilling tools, piping systems, storage tanks, and reactors, contributing to the safe and efficient operation of various components and equipment in this sector.

Characteristic:


  • Corrosion resistance: Inconel 600 rod has good corrosion resistance and can withstand corrosive media in the oil and gas industry, including acidic and alkaline media, salt water and hydrogen sulfide.
  • High-temperature stability: The alloy has excellent high-temperature stability and is able to maintain strength and structural stability in high-temperature environments, making it suitable for high-temperature applications in the oil and gas industry.
  • Mechanical properties: Inconel 600 rod has good mechanical properties, including high strength, good toughness and plasticity, and is able to meet the structural requirements in the oil and gas industry.

Advantage:


  • Corrosion Resistance: One of the main advantages of Inconel 600 rod in the oil and gas industry is its excellent corrosion resistance. It can withstand the erosion of corrosive media, reduce corrosion losses of pipelines and equipment, and extend service life.
  • Oxidation resistance: This alloy has good oxidation resistance and shows good stability in high temperature and oxidizing environments, which can reduce the impact of oxidation on pipelines and equipment.
  • High Temperature Performance: Inconel 600 rod maintains strength and structural stability under high temperature conditions and is suitable for high temperature equipment and pipelines in the oil and gas industry.


Application:


  1. Oil Drilling Tools: Inconel 600 rods can be used to make oil drilling tools such as drill pipes and drill bits. Its corrosion resistance and high strength can meet the requirements of drilling environment.
  2. Oil and gas pipelines: Inconel 600 bar can be used to manufacture pipeline systems for transporting oil and gas. Its corrosion resistance and high temperature stability can cope with the challenges of corrosive media and high temperature environments.
  3. Tanks and Reactors: Alloy rods are used in the manufacture of tanks and reactors in the oil and gas industry. Its corrosion resistance and high temperature stability protect media and equipment during storage and handling.

Other relevant knowledge points:


Inconel 600 rods also have applications outside the oil and gas industry, such as aerospace, chemical and other fields.
In the oil and gas industry, Inconel 600 rod is often required to comply with relevant material specifications and standards to ensure its quality and suitability.
When selecting and designing oil and gas industry applications using Inconel 600 rod, specific process conditions, media properties and engineering requirements need to be considered to ensure optimal performance and reliability.

Parameter:

Chemical Properties of Inconel 600

Element Percent
Nickel (plus Cobalt) (Min) 72
Chromium 14-17
Iron 6-10
Carbon (Max) .15
Manganese (Max) 1
Sulfur (Max) .015
Silicon (Max) .5
Copper (Max) .5

Type we could offer

AMS Number Alloy Misc./Shape
AMS 5540 Inconel 600
AMS 5540 Plate Inconel 600 Plate
AMS 5540 Sheet Inconel 600 Sheet
AMS 5540 Strip Inconel 600 Strip
AMS 5580 Custom Tube Inconel 600 Custom Tube
AMS 5580 Tubing Inconel 600 Tubing
AMS 5665 Bar Inconel 600 Bar
AMS 5665 Custom Tube Inconel 600 Custom Tube
AMS 5665 Ring Inconel 600 Ring
AMS 5961 Inconel 600 Wire

contact us

email:victory@dlx-alloy.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Oil And Gas Industry Alloy Rod Inconel 600 Rods With Antioxidant

Shape
Size(mm)
WIre
0.5-7.5
Rod/Bar
8.0-200
Strip
(0.5-2.5)*(5-180)
Tube
custom made
Plate
custom made
