Specifications
Place of Origin :
Beijing, China
Brand Name :
TCHD Video
Model Number :
MVR
Packaging Details :
Carton
Supply Ability :
10 Unit/Units per Month
Price :
$1,780.00 - $2,100.00/units
Power Source :
Electric
Warranty :
1 Year
After-sale Service :
Return and Replacement
Material :
Metal
Shelf Life :
1years
Quality Certification :
CE
Instrument classification :
Class I
Safety standard :
EN 149 -2001+A1-2009
Properties :
The Basis of Surgical Instruments
Application :
Arthroscope,Endoscope,B-mode ultrasound,X Ray image capture
Function :
Surgery image recorder
Feature :
Backup video and photos
Type :
Other
Port :
Beijing
Description

Medical Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video RecorderSafety Full HD Medical Video Recorder DVR H.264 Digital Data Video Recorder

Product Description

MediDVR records medical images & video clips from virtually any medical video device (endoscope, arthroscopy, surgical camera, C-Arms, ultrasound etc.). Video recording resolution up to 1080p. The videos & images recorded can be saved to a convenient USB flash drive, USB mobile hard drive, NAS or to the MediDVR’s internal hard drive.

Features:

Easily record crisp 1080p video and images

IP video preview and record

4.3” LCD and resistance touch screen

QR code scan for direct remote control by mobile phone or PC

mp4, mov video format all supported

Universal interface, works with almost all video interfaces

Universal storage, works with all major USB Flash Drive, NAS, USB HDD and SATA HDD

Support Full HD video up to 1080p@60fps

Support traditional USB foot pedal

Support USB handle

Network supported for live video streaming

USB standard keyboard support for patient information and notes

Small size, low cost and high quality

All inputs can be looped to DVI preview output

Replay videos easily

Shortcuts to quickly switch video source and storage media

Onboard microphone support, gain adjustable ≡ Unique and additional feature for PMD

Battery life up to five hours of video recording

Dual HDMI and SDI input

Very compact size for portable application

Automatic detection of input signal, resolution and frame rate.

Specifications

Power

Voltage

AC 110-240V 2A 50/60Hz
3 prong AC Jack Medical grade power filter and supply

Video
and

Video Encoder

H.264/AVC MP/HP

Resolution

1920×1080@25/30/50/60fps, 1280×720@50/60fps
480i/576i 1080i@50/60
SMPTE 425M/424M, 292M/274M/296M

Bit Rate

Max. 20Mbits/s, 3 level adj

Frame Rate

24/25/30fps, 50/60fps

Codec

H.264, mp4/mov file format

Rate Control

CBR/VBR


Jpeg, DICOM, BMP

Streaming

RTSP

Audio

Sampling

32-48KHz,16bits

Codec

AAC Stereo

Channels

2 with Automatic Gain Control MIC: 2.2VDC Bias, 2.2Kohm, <0.7VRMS -36db. MIC gain adj.

Interface

SDI input

1 x BNC, 75ohm, 800mVpp, SD/HD/3G

DVI Input

1x DVI, Receptacle

HDMI Input

1 x TYPE A, Receptacle

Preview

LCD 4.3”

SDI Loop Output

1xBNC, 75ohm, 800mVpp,HD/3G

Audio In

2CH, 2 x 3.5mm Jack, 20Kohm higher

Audio Out

2CH, 2 x 3.5mm Jack

Network

LAN: 100/1000M Base-T

Streaming

RTSP

USB

4 x USB, Type A, 2x front , 2 x rear

Remote

Mobile phone, PC, RESTFUL

Visible

3x Color LED

Alert

Buzz

LCD

4.3″ IPS, Resistance Touch

Button

Sealed Membrane, Fluid Resitant

Storage

External

2x USB Flash Drive, USB HDD

Disk Format

FAT32, up to 2T

Physical

Size

300x 211 x 97.5mm (11.8″ x 8.3″ x3.8″)

Weight

2.98kg (6lb ,7.7oz)

Operating

0°C to 45°C(32°F to 113°F)

Storage

-20°C to 60°C(-4°F to 140°F)

Safety Full HD Medical Video Recorder DVR H.264 Digital Data Video Recorder
