1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression
Specifications
Place of Origin :
Beijing, China
Brand Name :
TCHD
Model Number :
TC 310
Product name :
RTMP/RTSP/HTTP/TS quad band iptv streaming encoder server
Input :
HD MI
Network Protocol :
TS/HLS/RTSP/FLV/RTMP
Resolution :
1080p60
Audio :
3.5mm independent audio
Feature :
Ethernet streaming
Application :
Video conference,wedding, distance education, lunch event, webcasting
Compression Format :
H.264 encoding
Audio Compression :
AAC+/AAC++/MP3
Type :
Text/Picture/Rolling text
Packaging Details :
Carton box
Port :
Beijing
Supply Ability :
300 Piece/Pieces per Month
Price :
$110.00 - $130.00/pieces
Description

RTMP/RTSP/HTTP/TS independent audio 1080p60 quad band iptv streaming encoder server

1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression

Introduction

1080p60 Quad Band IPTV Streaming Encoder Server with AAC /AAC /MP3 Audio Compression

TC-310 HDMI encoder is a professional audio and video encoding products, which support 1 channel HDMI video input with embedded audio input and 1 x 3.5MM independent audio interface acquisition, quad streaming H.264 encoded output format,AAC+/AAC++/MP3 audio compression, support TS/HLS/RTSP/FLV/RTMP network protocols, it is easy to install, can add subtitles and logo, and there is no computer hardware compatibility issues.

Product Model

TC-310H

Video&Audio Input

Video Input

1XHDMI

Input Resolution

1920x1080/1680x1056/1280x720/1024x576/850x480/

720x576/720x540/720x480/720x404/704x576/640x480/

640x360/608x448/544x480/480x480/480x384/480x360/

480x320/480x272/480x270/400x320/400x224/352x480/

352x228/320x256/320x240/320x180/240x180/176x144

Audio Input

1xHDMI Embedded Audio

Audio Output

1xAudio Output

Video Parameters

Compression Format

H.264 Baseline Profile

H.264 Main Profile

H.264 High Profile

Video Frame Rate

5-60fp adjustable

Video Bit rate(kbit)

32-32000 adjustable

Audio Parameters

Audio input

HDMI/Analog

Audio Compression

AAC+/AAC++/MP3

Audio Frame Rate

44100/48000

Bit rate

12000-32000 adjustable

Net Parameters

Configuration Management

Web UI for system configuration Firmware up gradable

Network feature

Ethernet 10/100Mbps RJ45

Stream Type

Main and Sub Stream

Network Protocol

TS/HLS/RTSP/FLV/RTMP

OSD

Diaphaneity

0-128 adjustable

Type

Text/Picture/Rolling text

Area

4 area can be chosen

X coordinate

0-1920

Y coordinate

0-1080

Logo

4 logo available to be uploaded

General

Power

DC 12V, 2A

Power Consumption

<5W

Working temperature

-20℃~ - 60℃

Working humidity

<90%

Dimensions (mm)

107mm x 80mm x 30mm
