SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
Specifications
Place of Origin :
Beijing, China
Brand Name :
TCHD
Model Number :
60S
Input :
SDI
Network protocol :
RTMP / P2P / HLS
Video resolution :
Maximum support for 1080p60
Audio :
3.5mm audio
Feature :
4g and wifi live streaming
Application :
Live streaming, webcasting, broadcasting
Compression format :
H.265/H.264
APP control :
Support cellphone control
Type :
Dual streaming
Memory card capacity :
Maximum support 128G
Packaging Details :
Carton box
Port :
Beijing
Supply Ability :
500 Piece/Pieces per Month
Price :
$640.00 - $680.00/pieces
Description

Drone full HD sd input live streaming 4g and wifi encoder with rtmp protocol

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD VideoSDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD VideoSDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Introduction

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

TC-60S HD encoder is our newest professional HD audio & video encoding device with powerful functionality. It support H.264/H.265 encoding,dual-Streaming data.It is equipped with 1 channel SDI input .Its high integration and cost-effective design make this device widely used in variety of digital distribution systems. Support 4G/WIFI to RTMP streaming.

Name

SDI 4G video encoder

Series

60S

Video format

MP4

Compression format

H.265/H.264

Audio compression

AAC(48K)

Video input format

720p: 25/30/50/60/120 fps

1080i:50/60 fps

1080p:25/30/50/60 fps

Output resolution

1920*1080/1280*720/848*480

960*540/640*360/480*270

Video resolution

Maximum support for 1080p60

Memory card type

TF card

Memory card capacity

Maximum support 128G

WiFi

2.4G

4G network

All Netcom

SIM card type

MicroSIM Card

Power Interface

DC5V, 2000MA [Micro USB interface]

Power frequency

50HZ/60HZ

Battery capacity

3.8V / 4000mAH

Maximum power consumption

4W

Weight

260g

Dimensions (mm)

110*70*30

Language

Simplified Chinese/English

Operating system

Android 4.1+ & IOS 7+

Network protocol

HLS/RTMP/P2P

Working temperature

0℃~45℃

Working humidity

15%~85%

Support band

FDD LTE: Band 1,Band 3,Band 8,all bands with diversity

TDD LTE: Band39,Band40,Band41(38),all bands with diversity

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Packing List

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Applications

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Related Products

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Packaging & Shipping

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Advantages

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video

Company Information

SDI Input Live Streaming 4G and WiFi Encoder with RTMP Protocol for Drone Full HD Video
