Specifications
Brand Name :
EFF
Model Number :
eff/
Certification :
CE/FCC
Place of Origin :
CHINA
MOQ :
1m2
Price :
according to the specific requirement
Payment Terms :
T/T, Western Union
Supply Ability :
2000m2/month
Delivery Time :
15-20 days
Packaging Details :
wooden cases/ flight cases
PIXEL PITCH :
JB/P2.5MM
LEDs :
SMD2121
Brightness :
1200nit
Refresh rate :
2880Hz
Cabinet :
Aluminum
Maintaining :
Rear
Description

P2.5mm Super Slim LED Video Wall, Aluminum cabinet, 14bit Colors,High refresh Rate

Quick Detail:

1. ≤1mm surface level up, smooth video.

2. Perfect quality and stability, 24/7 running.

3. Front or Rear Access Service.

4. 2 years warranty.

5. Long lifespan up to 100,000 hours.

6. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION.

Description:

1. High Resolution

160000 dots per ㎡.

2. Excellent Performance

High refresh rate and enough brightness make the LED display be capable to show all kinds of HD video, images vividly.

3. 2 years warranty

Free replacement and maintenance for spare parts is offered within warranty period. Permanent

maintenance service is offered before product’s life expires.

4. Front or Rear access Service Available

Our many outdoor screens have been used by our clients around the world for 3-5 years and no product issues are called.

Applications:

Comprehensive purposes like Cinema, Theatre, trade show, Bar etc.

Advantages:

1. seamless assembling

2. Brightness automatical adjustment

3. High-definition visual effect

4. High thermal conductivity Alloy cabinet, better heat dissipation

5. Fan-free design, energy saving, more stable,

6. 140〫 wide view angle,

7. Approved by RoHS certification, Lead-free, enviromental design

8. Both above and below use stainless steel hasp

9. Ergonomic handle design, convenient handling

10. High performance and adjustable side lock, tools free.

11. International standards air plug on Power connectors, easy, fast and safe.

12. Receiving card to card with LAN cable, simple, less failure rate

13. Diversification assembling

Specifications:

Product Series JB/P2.5MM
Pixel Pitch 2.5mm
Pixel Package SMD2121
LED Configuration 1R1G1B
Pixel Density 160000 Pixels/㎡
Module Size 160mm x 160mm
Module Resolution 64 x 64 dots
Suggested Cabinet Size 480mm x480mm x 80mm
Cabinet Resolution 192 x 192 dots
Cabinet Material Aluminum
Cabinet Weight < 10kg/㎡
Brightness 1200 nits
Color Temperature 3000-12000K
Viewing Angle H-120°/ V-120°
Driving Mode 1/16
Refresh Rate 960-2880Hz
Frame Frenquency 60Hz
Grey Level 4096-16384
Number of Color 1 billion
Input Maximum Power 530 W/㎡
Input Voltage AC220±10%, AC110 ±10%
Input Frequency 50-60Hz
External Interface S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc
IP Rating IP21

Our Services:

· Spare parts: necessary spare parts are provided together with products to customers.
· Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
· Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
· Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
