Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event
Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event
Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event
Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event
Specifications
Brand Name :
EFF
Model Number :
eff/
Certification :
CE/FCC
Place of Origin :
CHINA
MOQ :
1 set
Price :
according to differnt style
Supply Ability :
according to diffeent products
Delivery Time :
15-35 workding days after recieved payment
Packaging Details :
plywood export packing
Sreen Dimension :
Customize
Display Way :
Video
Tube chip color :
Full Color
viewing ditance :
1.5-50m
cabinat size :
500*500 mm
scan mode :
1/16
Description

HD 3.97mm Full Color Indoor LED Video Wall P4 LED Display for Rental Event

Product Features:


1. SMD LED encapsulation confirm wide view angle, above 140° for horizontal and vertical, without no strobe and color casting from different angle,good vision effect.

2. Black body LEDs ensure high contrast ratio and high resolution.

3. Cabinet is made with Die-casting Aluminum material for strong and durable.

4. Light weight and super slim thickness, easy to move and be portable.

5. Cabinet with fast locks and aviation plugs for connecting easily with each other, suit for fixed or hung install,easy to install and dismantle.

6. Exquisite and tasteful appearance due to structural wire layout.

7. Vivid and exact picture, minimum noise, advanced test equipment, support any PC operation system and play a variety of information like video,word, flash, music, clock, graph etc.

8. Packed with flight case, convenient to be collected and transported better for rental use


Basic promise from JB:


A: Full automatic production to control our high quality, best color consistency and get better performance.


B: Energy saving, low power consumption and long lifespan 10,000 hours (about 10 years).


C: We guarantee that the equipment we provide are brand new, complete and unused.


D: Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).


E: Our quality control throughout every process from materials-production- test-package-delivery(led lamp, module.

Data Sheet:

Modle No.

JB/3.91-R
Pixel Pitch 3.91mm
Pixel Density 65536dots/m²
Brightness ≥1000-1300nit
LED Encapsulation SMD2427
Drive Mode 1/13 scan
Cabinet Resolution 128*128 dots
Cabinet Weight ≤9KG
Max Pqwer Consumption ≤680w/m²
Average Power Consumption ≤340w/m²
Best Viewing Angle H:160° V:120°
Refresh Rate <1920Hz
Grey Scale 14-16bit
Best Viewing Distance 1.5-50m
Frame Rate 60Hz
Drive IC MBI5020
Module Size 125*250mm
Cabinet Size(W*H*D) 500*500*86mm
Pixel Configuration 1R1G1B
Color Temperature 6500-9500k
Protection Level IP31
Cabinet Material Die-casting Aluminum Alloy Cabinet
Operation Voltage 220v/50Hz,110v/60Hz
Working Humidity 10%-90%
Working Temperature -20ºC--+50ºC
Video Signal RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION,etc.

Here We Are:

Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event

Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event

Waterproof Customize HD LED Wall 3.97mm P4 Light Weight For Rental Event
