Cost Effective 4mm Indoor Advertising LED Video Display Sign for Restaurant

Cost effective 4mm indoor advertising led video display sign for restaurant

P4 HD indoor LED sign is popular in the market due to its high definition and good price. P4 is our mature product, both quality and price are very good as we produce a lot. Also we are pushing the sales of this item. Welcome to enquire!

Some advantages and features bellow.

1. High resolution: 62,500pixels/m2, can show extremely high quality video, images and texts

2. Cabinet size: 1024*1024mm with 2 receiving cards inside to improve the refresh rate so that it won't have scaning line when take pictures or video

3. Large viewing angle, Up to 140° (Horizontal & Vertical) by using our specially designed mask.

4. High reliability, fully produced by auto-machine, SMD LED is with high uniformity, stability & reliability, that guarantees the perfect performance of the screen.

5. Low Power Consumption, can save energy extremely, and advocate environment-protection.

6. Has fast heating spread, to protect screen effectively and increase the use life largely.

7. We can design the cabinet as slim body & light weight, Easy maintenance, Long use life.

8. This P4 LED display screen can show all kinds of word, text, graph, pictures, flashes, video, 2-dimension, 3-dimension cartoon and any other formats with your PC does synchronously.

9. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL, DVI, AVI, VGA, SDI, MOV, MPG, etc.

10. Applications indoor, It can be used in advertisement, stage, stadium, exhibition, TV-Show, mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc.

Product Description:

Full color indoor P2/2.5mm LED screens with integrated full color LED block modules as unit is another deeper revolutionary development in the LED screens industry. It shows a super fine and high quality picture on the LED screens. Built specially for the less viewing distance like High-level Conferences and Forums, TV station and News Channel Events, Video monitoring command centre, broadcast, Hotel functions, Auditorium, conference room, meeting rooms, banquet hall and exhibition presentations, traffic control, government offices, studio and many other places.

• Cabinet Dimension: 480mm X 480mm
• Brightness: >800-1000 cd/m2
• Warranty : 2 yrs
• Services : Online Service, Onsite Service, Telephonic Service, Direct Visit.

• Technical Prameters
  PROJECT				P2.5 indoor conference LED video wall
  Pixel pitch				2.5mm
  Pixel density				111111 Pixels/sqm
  Module size(W*H)				192 W(mm)		96 H(mm)
  Module pixels(W*H)				64 Pixels(W)		32 Pixels(H)
  Pixel configuration				1Red 1Green 1Blue
  Drive mode				constant current driving 1/16 scan
  LED lamp type				SMD2121(Black body)
  Cabinet size(W*H*D)				576 W(mm)		576 H(mm)
  Cabinet resolution				192 Pixels(W)		192 Pixels(H)
  Color scale				65,536 degree
  View angle(H/V)				140/120 degree
  Brightness (White balance)				≥1300cd/sqm.
  Power consumption(one cabinet)				Max:1100W/sqm. Average:400W/sqm.
  Operating Voltage				AC100V±10% or 220V ±10%; 50---60HZ
  Net weight				39 Kg/M 2 for Iron cabinet
  Operating temperature				-30°C----+60°C
  Operating humidity				10%_95%RH
  Life time				≥100,000hours
  MTBF				5,000 hours
  Whole Display Flatness				≤0.3mm Juncture
  Frame frequency				>60 Hz/s
  Refresh rate				≥2000Hz /s
  Control distance				100m (without repeater), single mode fiber:20km, multi mode fiber: 500m
  Power				110V/220V±15% 50--60Hz
  LED control system				LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable
  Operating system				Windows 2000 / Windows Xp / Windows 7
  Protections for outdoor display				IP31
  Maintenance way				Rear Access
  Accepting signal with video processor				PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
